EGH3100FFB - 100Amp Circuit Breaker

EGH3100FFB - 100Amp Circuit Breaker

The Eaton EGH3100FFB is a 100 Amp, three-pole molded case circuit breaker designed for use in compatible Eaton Series G EG frame electrical distribution systems. Whether you're replacing an existing breaker during scheduled maintenance or restoring equipment to its original operating condition, this complete breaker is engineered to provide the proper form, fit, and function for compatible installations. Its bolt-on terminals allow for secure installation, while the T186 thermal-magnetic trip unit helps protect electrical systems by responding automatically to overloads and short circuits before they can cause damage to connected equipment. Built to last, the EGH3100FFB is a dependable choice for electricians, contractors, and maintenance professionals who want to keep commercial and industrial electrical systems operating safely while preserving the original equipment design.

Key Features and Benefits

• 100 Amp continuous current rating
• Three-pole molded case circuit breaker
• Designed for compatible Eaton Series G EG frame equipment
• Complete breaker assembly for form, fit, and functional replacement
• Bolt-on terminal configuration for secure installation
• T186 thermal-magnetic trip unit
• Helps protect electrical systems from overloads and short circuits
• Suitable for 50/60 Hz electrical distribution systems
• Built to last for dependable service in properly maintained electrical systems


Technical Specifications

• Catalog Number: EGH3100FFB

• Manufacturer: Eaton

• Series: Series G

• Product Type: Molded Case Circuit Breaker

• Frame: EG

• Frame Type: Complete Breaker

• Amperage Rating: 100 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347 VAC

• Frequency Rating: 50/60 Hz

• Trip Type: T186 Thermal-Magnetic

• Terminal Type: Bolt-On

• Interrupting Ratings:
  • 100 kAIC @ 240 VAC
  • 65 kAIC @ 480 VAC
  • 35 kAIC @ 600Y/347 VAC
• Dimensions:
  • Height: 5.5 in.
  • Width: 3.0 in.
  • Depth: 2.99 in.
• Weight: Approximately 2.91 lbs.


Material Compliance and Certifications

The EGH3100FFB is manufactured to meet recognized electrical safety and compliance standards.

• UL Listed
• CSA Certified
• IEC Rated
• CE Marked


Where It Works Best

• Commercial office buildings
• Manufacturing facilities
• Industrial plants
• Healthcare facilities
• Educational campuses
• Warehouses and distribution centers
• Electrical distribution panels
• Branch circuit protection applications
• Existing power distribution systems designed for compatible Eaton Series G EG frame breakers
