EGH3080FFGV 80Amp Circuit Breaker

EGH3080FFGV 80Amp Circuit Breaker

The Eaton EGH3080FFGV is an 80 Amp, three-pole molded case circuit breaker designed for use in compatible Series G EG frame electrical distribution systems. Whether you're replacing an existing breaker during scheduled maintenance or restoring a system to its original operating condition, this complete breaker provides the correct form, fit, and function for compatible equipment. Featuring line and load terminals and a T186 thermal-magnetic trip unit, it helps protect electrical systems by automatically interrupting power during overloads and short circuits, helping reduce the risk of damage to connected equipment. Built to last, the EGH3080FFGV offers electricians, facility managers, and maintenance professionals a dependable replacement solution to keep commercial and industrial electrical systems operating reliably.

Key Features and Benefits

• 80 Amp continuous current rating
• Three-pole molded case circuit breaker
• Designed for compatible Eaton Series G EG frame equipment
• Complete breaker assembly for form, fit, and functional replacement
• Line and load terminal configuration for installation flexibility
• T186 thermal-magnetic trip unit helps protect against overloads and short circuits
• Calibrated for operation at 50°C
• Suitable for 50/60 Hz electrical distribution systems
• Built to last for dependable service in properly maintained electrical systems


Technical Specifications

• Catalog Number: EGH3080FFGV

• Manufacturer: Eaton

• Series: Series G

• Product Type: Molded Case Circuit Breaker

• Frame: EG

• Frame Type: Complete Breaker

• Amperage Rating: 80 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347 VAC

• Frequency Rating: 50/60 Hz

• Trip Type: T186 Thermal-Magnetic

• Terminal Type: Line and Load

• Calibration: 50°C

• Interrupting Ratings:
  • 100 kAIC @ 240 VAC
  • 65 kAIC @ 480 VAC
  • 35 kAIC @ 600Y/347 VAC
• Dimensions:
  • Height: 5.5 in.
  • Width: 3.0 in.
  • Depth: 2.99 in.
• Weight: Approximately 3 lbs.


Material Compliance and Certifications

The EGH3080FFGV is manufactured to meet recognized electrical safety and compliance standards.

• UL Listed
• CSA Certified
• IEC Rated
• CE Marked


Where It Works Best

• Commercial office buildings
• Manufacturing facilities
• Industrial plants
• Healthcare facilities
• Educational campuses
• Warehouses and distribution centers
• Electrical distribution panels
• Branch circuit protection applications
• Existing power distribution systems designed for compatible Eaton Series G EG frame breakers
