EGH3070FFGV 70A Circuit Breaker

EGH3070FFGV 70A Circuit Breaker

Introducing the Eaton EGH3070FFGV, a premium Series G molded case circuit breaker designed for optimal performance and reliability. This three-pole, 70A circuit breaker operates at 600Y/347 Vac, providing robust protection for various electrical systems. Engineered with fixed thermal and magnetic trip mechanisms, it ensures consistent and safe operation in demanding environments. The Eaton EGH3070FFGV is an essential component for anyone seeking reliable circuit protection with high interrupting capacity and compliance with international standards.

Key Features and Benefits:

• High Interrupting Capacity: Boasts a remarkable interrupting capacity of 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, and 35 kAIC at 600Y/347 Vac, ensuring exceptional performance in fault conditions.
• Robust Construction: Built with durable materials and advanced engineering to withstand harsh operating conditions.
• Versatile Application: Ideal for use in industrial, commercial, and residential settings requiring high reliability and safety.
• Fixed Thermal and Magnetic Trip: Provides consistent and reliable protection against overloads and short circuits.
• Easy Installation: Designed for straightforward installation with line and load terminals, making it a convenient choice for various applications.

Technical Specifications:

• Amperage Rating: 70A
• Voltage Rating: 600Y/347 Vac
• Interrupting Capacity: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, 35 kAIC at 600Y/347 Vac
• Trip Type: Fixed Thermal, Fixed Magnetic
• Frame Type: EG Frame
• Frequency Rating: 50/60 Hz
• Calibration: 50°C
• Poles: Three-Pole
• Dimensions: 2.99 in (Length) x 5.5 in (Height) x 3 in (Width)
• Weight: 3 lb

Material Compliance and Certifications:

• CE Marked
• CSA Certified
• IEC Rated
• UL Listed

Suitability:

• The Eaton EGH3070FFGV is perfect for applications requiring high reliability and safety standards. It is suitable for use in control panels, motor protection, and general circuit protection in both commercial and industrial environments. This circuit breaker is engineered to provide superior protection and performance, making it an excellent choice for electricians, engineers, and maintenance professionals seeking top-quality electrical components.

Equip your electrical systems with the Eaton EGH3070FFGV circuit breaker to ensure superior performance, protection, and peace of mind for your most demanding electrical applications.
