EGH3060FFB 60Amp Circuit Breaker

EGH3060FFB 60Amp Circuit Breaker

The Eaton EGH3060FFB is a 60 Amp, three-pole molded case circuit breaker designed for use in compatible Series G EG frame electrical distribution systems. Whether you're replacing an existing breaker during routine maintenance or keeping a commercial or industrial power system operating as intended, this complete breaker provides the proper form, fit, and function for compatible installations. Its bolt-on terminals create secure electrical connections, while the T186 thermal-magnetic trip unit helps protect connected equipment by responding to overloads and short circuits before they become larger problems. Built to last, the EGH3060FFB is a dependable choice for electricians, maintenance professionals, and facility managers who need a replacement breaker that matches the original equipment specifications.

Key Features and Benefits

• 60 Amp continuous current rating
• Three-pole molded case circuit breaker
• Designed for compatible Eaton Series G EG frame equipment
• Complete breaker assembly for form, fit, and functional replacement
• Bolt-on terminal design for secure electrical connections
• T186 thermal-magnetic trip unit helps protect against overloads and short circuits
• Suitable for 50/60 Hz electrical systems
• Built to last for dependable operation in properly maintained electrical systems


Technical Specifications

• Catalog Number: EGH3060FFB

• Manufacturer: Eaton

• Series: Series G

• Product Type: Molded Case Circuit Breaker

• Frame: EG

• Frame Type: Complete Breaker

• Amperage Rating: 60 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347 VAC

• Frequency Rating: 50/60 Hz

• Trip Type: T186 Thermal-Magnetic

• Terminal Type: Bolt-On

• Interrupting Ratings:
  • 100 kAIC @ 240 VAC
  • 65 kAIC @ 480 VAC
  • 35 kAIC @ 600Y/347 VAC
• Dimensions:
  • Height: 5.5 in.
  • Width: 3.0 in.
  • Depth: 2.99 in.
• Weight: Approximately 2.15 lbs.


Material Compliance and Certifications

The EGH3060FFB is manufactured to meet recognized industry safety and compliance standards.

• UL Listed
• CSA Certified
• IEC Rated
• CE Marked


Where It Works Best

• Commercial office buildings
• Manufacturing facilities
• Industrial plants
• Educational institutions
• Healthcare facilities
• Warehouses and distribution centers
• Electrical distribution panels
• Branch circuit protection applications
• Existing power distribution systems designed for compatible Eaton Series G EG frame breakers
