EGH3020FFB - 20Amp Circuit Breaker

EGH3020FFB - 20Amp Circuit Breaker

When you're servicing an existing electrical distribution system, choosing a compatible replacement breaker helps keep your project on schedule and your equipment protected. The EGH3020FFB is a 20 Amp, three-pole molded case circuit breaker from Eaton's Series G EG frame family, designed to provide dependable overload and short-circuit protection in compatible commercial and industrial electrical systems. Built as a complete breaker with bolt-on terminals, it offers the form, fit, and function needed to replace an existing compatible breaker while maintaining the original electrical specifications of your installation. Whether you're performing preventive maintenance, replacing a worn breaker, or restoring equipment to service, the EGH3020FFB is designed to deliver the compatibility and performance your system requires.

Key Features and Benefits

• 20 Amp continuous current rating
• Three-pole molded case circuit breaker
• Complete breaker for compatible Series G EG frame equipment
• Bolt-on terminal design for secure electrical connections
• 50/60 Hz frequency rating
• T186 trip unit for dependable overload and short-circuit protection
• Compact design for installation in compatible equipment
• Built to provide long-lasting service in commercial and industrial environments


Technical Specifications

• Catalog Number: EGH3020FFB

• Product Type: Molded Case Circuit Breaker

• Series: Series G

• Frame: EG

• Frame Type: Complete Breaker

• Amperage Rating: 20 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347 VAC

• Frequency: 50/60 Hz

• Trip Type: T186

• Terminal Type: Bolt-On

• Interrupting Ratings:
  • 100 kAIC @ 240 VAC
  • 65 kAIC @ 480 VAC
  • 35 kAIC @ 600Y/347 VAC
• Dimensions:
  • Height: 5.5 in.
  • Width: 3.0 in.
  • Depth: 2.99 in.
• Weight: Approximately 2.9 lbs.


Material Compliance and Certifications

• UL Listed
• CSA Certified
• IEC Rated
• CE Marked


Where It Works Best

• Commercial office buildings
• Manufacturing facilities
• Healthcare facilities
• Educational institutions
• Warehouses and distribution centers
• Electrical distribution panels
• Branch circuit protection applications
• Existing power distribution systems using compatible Series G EG frame breakers
