EGH3015FFB - 15Amp Circuit Breaker

EGH3015FFB - 15Amp Circuit Breaker

When you're maintaining an existing electrical distribution system, having the right replacement breaker is essential. The EGH3015FFB is a 15 Amp, three-pole molded case circuit breaker from Eaton's Series G EG frame family, designed to provide dependable overload and short-circuit protection in compatible commercial and industrial equipment. Built as a complete breaker with bolt-on terminals, it offers the form, fit, and function needed to replace an existing compatible breaker while preserving the original electrical design of your system. Whether you're performing preventive maintenance or replacing a breaker that has reached the end of its service life, the EGH3015FFB helps keep your electrical infrastructure operating with confidence. Designed for 600Y/347 VAC systems operating at 50/60 Hz, the EGH3015FFB is built to last and is well suited for a wide range of power distribution applications.

Key Features and Benefits

• 15 Amp continuous current rating
• Three-pole molded case circuit breaker
• Complete breaker for compatible Series G EG frame equipment
• Bolt-on terminal design for secure electrical connections
• 50/60 Hz frequency rating
• T186 trip unit for dependable overload and short-circuit protection
• Compact design for installation in compatible equipment
• Built to provide long-lasting service in commercial and industrial environments


Technical Specifications

• Catalog Number: EGH3015FFB

• Product Type: Molded Case Circuit Breaker

• Series: Series G

• Frame: EG

• Frame Type: Complete Breaker

• Amperage Rating: 15 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347 VAC

• Frequency: 50/60 Hz

• Trip Type: T186

• Terminal Type: Bolt-On

• Interrupting Ratings:
  • 100 kAIC @ 240 VAC
  • 65 kAIC @ 480 VAC
  • 35 kAIC @ 600Y/347 VAC
• Dimensions:
  • Height: 5.5 in.
  • Width: 3.0 in.
  • Depth: 2.99 in.
• Weight: Approximately 2.91 lbs.


Material Compliance and Certifications

The EGH3015FFB is manufactured to meet recognized industry safety and quality standards, making it a dependable option for maintaining compatible electrical systems.

• UL Listed
• CSA Certified
• IEC Rated
• CE Marked


Where It Works Best

• Commercial office buildings
• Manufacturing facilities
• Educational campuses
• Healthcare facilities
• Warehouses and distribution centers
• Electrical distribution panels
• Branch circuit protection applications
• Existing power distribution systems using compatible Series G EG frame breakers
