EGB34080 - 80Amp Circuit Breaker

EGB34080 - 80Amp Circuit Breaker

Discover the robust and reliable EGB34080 Miniature Circuit Breaker, a high-performance solution from Schneider Electric designed to safeguard your low-voltage electronics. Engineered with precision, this E-Frame circuit breaker boasts an 80A current rating and a three-pole configuration, ensuring optimal protection for your electrical systems. With a maximum operating voltage of 480Y/277 VAC and an impressive interrupt rating of 65 kA at 120 VAC, the EGB34080 is the perfect choice for a wide range of industrial and commercial applications.

Key Features and Benefits:

• High Current Capacity: The EGB34080 supports a line-rated current of 80A, making it suitable for demanding electrical loads.
• Superior Interrupt Rating: With a maximum interrupt rating of 65 kA at 120 VAC, this circuit breaker ensures exceptional protection against short circuits.
• Thermal-Magnetic Trip Unit: Combines both thermal and magnetic trip functions for comprehensive overload and short-circuit protection.
• Durable Construction: Designed to endure harsh environments, the EGB34080 offers reliable performance over a long service life.
• Easy Installation: Bolt-on mounting allows for straightforward installation in Square D NF panelboards.

Technical Specifications:

• Device Short Name: EGB
• Current Rating: 80A
• Number of Poles: 3
• Operating Voltage: 480Y/277 VAC
• Interrupt Rating: 65 kA at 120 VAC, 35 kA at 480Y/277 VAC
• Trip Unit Technology: Thermal-Magnetic
• Mounting Mode: Bolt-on
• Height: 5.66 inches (143.76 mm)
• Width: 2.94 inches (74.68 mm)
• Depth: 4.05 inches (102.87 mm)
• Net Weight: 4 lb (1.81 kg)

Material Compliance and Certifications:

• Certifications: cULus certified, ensuring compliance with North American safety standards.
• Environmental Compliance: RoHS and REACh compliant, reflecting Schneider Electric's commitment to sustainable and environmentally friendly products.
• Green Premium Label: This product meets Schneider Electric‰۪s rigorous standards for environmental performance and sustainability.

Suitability:

• The EGB34080 circuit breaker is ideal for use in industrial and commercial environments requiring robust protection for low-voltage electrical systems. It is specifically designed for use in Square D NF panelboards, providing reliable protection and enhancing the safety and efficiency of your electrical installations.

Invest in the EGB34080 Miniature Circuit Breaker today and experience the confidence that comes with superior electrical protection and performance.
