EGB34060 - 60 Amp Circuit Breaker

EGB34060 - 60 Amp Circuit Breaker

When you need a dependable replacement breaker that matches the original equipment, the EGB34060 60-Amp, 3-pole circuit breaker is designed to get the job done. Built for use in NF panelboards, this bolt-on circuit breaker provides the form, fit, and function needed to maintain existing electrical distribution systems without unnecessary modifications. Whether you're performing preventive maintenance, replacing a failed breaker, or servicing a commercial facility, the EGB34060 helps keep compatible systems operating as intended. Built to last, it's a practical solution for facilities that rely on proven electrical equipment every day.

The EGB34060 features a thermal-magnetic trip unit that delivers dependable protection against both overloads and short-circuit faults. Its thermal element responds to sustained overcurrent conditions, while the magnetic element responds quickly during high-fault events to help protect connected equipment.

Key Features and Benefits

• 60 Amp continuous current rating
• 3-pole configuration for three-phase electrical systems
• Bolt-on mounting for secure installation in compatible NF panelboards
• Thermal-magnetic trip unit helps protect against overloads and short circuits
• Trip indicator allows for quick visual identification of a tripped breaker
• Rated for systems up to 480Y/277 VAC
• Interrupt ratings up to:
  • 65kA @ 120 VAC
  • 65kA @ 120/240 VAC
  • 65kA @ 240 VAC
  • 35kA @ 277 VAC
  • 35kA @ 480Y/277 VAC
• HACR rated for compatible HVAC applications
• Designed as a form, fit, and functional replacement for compatible legacy systems
• Built to last for dependable long-term service


Technical Specifications

• Catalog Number: EGB34060

• Rated Current: 60 Amps

• Number of Poles: 3

• Frame Type: E-Frame (EGB Series)

• Mounting Type: Bolt-On

• Maximum Operating Voltage: 480Y/277 VAC

• Trip Unit Technology: Thermal-Magnetic

• Trip Unit Rating: 1800A

• Holding Current: 630A

• Protection Type: Overload and Short-Circuit

• Interrupt Ratings:
  • 65kA @ 120 VAC
  • 65kA @ 120/240 VAC
  • 65kA @ 240 VAC
  • 35kA @ 277 VAC
  • 35kA @ 480Y/277 VAC
• Electrical Connections: Aluminum lugs

• Compatible Wire Range:
  • Aluminum: AWG 12–2/0
  • Copper: AWG 14–2/0
• Terminal Tightening Torque:
  • 34.5 lb-in (3.9 N·m) for AWG 14–10
  • 49.6 lb-in (5.6 N·m) for AWG 8–2/0
• Operating Temperature: Calibrated for 40°C (104°F)

• Dimensions: 5.66" H × 2.94" W × 4.05" D

• Weight: Approximately 4 lbs


Material Compliance and Certifications

• cULus Listed
• HACR Rated
• TAA Compliant
• Calibrated for operation in ambient temperatures up to 40°C (104°F)


Where It Works Best

• Commercial office buildings
• Industrial manufacturing facilities
• Warehouses and distribution centers
• Educational campuses
• Healthcare facilities
• HVAC equipment circuits
• Three-phase power distribution systems
• General commercial electrical panels
