EGB34035 - 35Amp Circuit Breaker

EGB34035 - 35Amp Circuit Breaker

The EGB34035 is a top-tier miniature circuit breaker designed to deliver reliable and efficient protection for your electrical systems. With a robust 35A, 3-pole configuration and a maximum voltage rating of 480Y/277 VAC, this bolt-on circuit breaker is engineered for durability and high performance. Ideal for use in lighting panelboards, it ensures superior overload and short-circuit protection, making it a perfect choice for both commercial and industrial applications.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Provides accurate protection by combining both thermal (overload) and magnetic (short-circuit) trip elements.
• High Interrupt Rating: Capable of handling up to 65 kA at 240 VAC, ensuring robust protection against electrical faults.
• Long Lifespan: Engineered for a service life of up to 20 years, offering long-term reliability and cost-effectiveness.
• Bolt-On Design: Simplifies installation and provides a secure fit in NF panelboards, enhancing safety and performance.

Technical Specifications:

• Amperage: 35A
• Poles: 3
• Voltage Rating: 480Y/277 VAC
• Interrupting Rating: 65 kA at 240 VAC
• Operating Voltage: 480Y/277 VAC
• Holding Current: 630A
• Trip Current: 1800A
• Mounting Type: Bolt-on
• Height: 5.66 in (143.76 mm)
• Width: 2.94 in (74.68 mm)
• Depth: 4.05 in (102.87 mm)
• Net Weight: 4 lb (1.81 kg)

Material Compliance and Certifications:

• Certifications: UL Listed for High Intensity Discharge (HID) and HACR rated
• Compliance: Complies with RoHS and REACh regulations, ensuring environmental safety and sustainability.
• Green Premium Label: Schneider Electric's commitment to providing products with superior environmental performance, transparency on environmental impacts, and circular, low-CO2 designs.

Suitability:

• The EGB34035 circuit breaker is specifically designed for Square D NF panelboards, offering reliable protection for low-voltage electronics. Its robust construction and advanced features make it suitable for a wide range of applications, including commercial lighting systems and industrial environments where safety and efficiency are paramount. With easy installation and long-term durability, this miniature circuit breaker is an excellent investment for ensuring the safety and reliability of your electrical infrastructure.

The EGB34035 Mini Circuit Breaker offers a reliable, durable, and environmentally friendly solution for protecting your electrical systems, ensuring long-term safety and efficiency in a variety of applications.
