EGB34025 - 25 Amp Circuit Breaker

EGB34025 - 25 Amp Circuit Breaker

The EGB34025 Mini Circuit Breaker is a dependable, high‑performance protection device designed for lighting panelboards and general electrical distribution panels. Whether you’re upgrading an existing setup or installing a fresh panelboard, this breaker brings dependable protection and long-term reliability. Its compact yet heavy‑duty build, combined with a thermal‑magnetic trip mechanism, delivers consistent protection against overloads and short circuits, keeping your electrical system safe and efficient.

Key Features and Benefits

• High interrupt capacity: With a 65 kA maximum interrupt rating at 120 VAC, the EGB34025 offers excellent protection against short circuits and fault conditions.
• Long service life: Engineered for up to 20 years of dependable operation, giving you peace of mind that it’s a lasting investment.
• Thermal‑magnetic trip unit: Uses a dual trip mechanism—thermal for overloads and magnetic for short circuits—for dependable, fast-acting protection.
• Secure mounting design: Bolt‑on configuration ensures a solid, stable installation, compatible with standard NF‑style panelboards.
• Flexible wiring compatibility: Accepts AWG 14…AWG 6 copper or AWG 12…AWG 6 aluminum conductors via aluminum lugs, making it versatile for many wiring scenarios.

Technical Specifications

• Current Rating: 25 Amps
• Number of Poles: 3
• Operating Voltage: 480Y/277 VAC
• Interrupt Rating: 65 kA max at 120 VAC
• Dimensions:
  • Height: 5.66 in
  • Width: 2.94 in
  • Depth: 4.05 in
• Weight: 4 lb (1.81 kg)
• Connection Type: Aluminum lugs; compatible with AWG 12…AWG 6 aluminum and AWG 14…AWG 6 copper wires
• Operating Temperature: Rated for operation up to 104 °F (40 °C)
• Listings / Ratings: UL Listed · HACR rated · HID rated

Material Compliance and Certifications

• RoHS Compliance: The EGB34025 is built in compliance with the RoHS directive, meaning all materials used meet strict environmental and safety standards.
• Green Premium Label: Reflects its environmentally friendly manufacturing processes and reduced ecological footprint.
• Certifications: UL Listing, HACR, and HID ensure it meets rigorous industry safety requirements.

Where It Works Best

• This 25 Amp Mini Circuit Breaker shines in both commercial and residential lighting panelboard applications. It’s especially suited for facilities or homes where dependable protection against electrical overloads and short circuits is crucial. Ideal for upgrading older panelboards or constructing new lighting distribution systems, the EGB34025 offers reliable, long-term service — a wise choice for contractors, electricians, and property owners seeking consistent, worry-free performance.
