EGB34020 - 20Amp Circuit Breaker

EGB34020 - 20Amp Circuit Breaker

The EGB34020 is a top-tier miniature circuit breaker specifically engineered for reliable and robust protection of low-voltage electronics in lighting panelboards. This 20A, 3-pole circuit breaker operates at 480Y/277 VAC with a maximum interrupt rating of 65 kA, providing exceptional overload and short-circuit protection. Crafted for direct mounting onto NF panelboards, it promises unmatched durability with a lifespan of up to 20 years.

Key Features and Benefits:

• High Interrupt Rating: With a maximum interrupt rating of 65 kA at 120 VAC, it ensures superior protection against short circuits.
• Thermal-Magnetic Trip Unit: Combines thermal and magnetic trip elements for enhanced overload and short-circuit protection.
• Long-lasting Durability: Designed to last up to 20 years, offering reliable protection and performance.
• Easy Installation: Bolt-on mounting simplifies installation in NF panelboards.

Technical Specifications:

• Frame Type: E-Frame
• Amperage: 20A
• Number of Poles: 3
• Voltage: 480Y/277 VAC
• Interrupt Rating: 65 kA max at 120 VAC
• Mounting Mode: Bolt-on
• Dimensions: Height: 5.66 in, Width: 2.94 in, Depth: 4.05 in
• Weight: 4 lb (1.81 kg)

Material Compliance and Certifications:

• UL Listed: Ensures compliance with industry standards for safety and performance.
• HACR Rated: Suitable for heating, air conditioning, and refrigeration applications.
• RoHS Compliance: Meets EU standards for the restriction of hazardous substances.
• Green Premium‰ã¢ Label: Certified for best-in-class environmental performance, promising low CO2 emissions and compliance with the latest regulations.

Suitability:

• The EGB34020 circuit breaker is ideal for use in Square D NF panelboards, providing dependable protection for lighting systems and other low-voltage applications. Its high interrupt rating and thermal-magnetic trip unit make it suitable for commercial and industrial environments where safety and reliability are paramount.

The EGB34020 Miniature Circuit Breaker is more than just a component; it's a crucial safeguard for your electrical systems, designed to offer peace of mind through its robust performance and protection features. Explore more about this essential circuit breaker today and ensure your systems remain secure and compliant.
