EGB34015 - 15Amp Circuit Breaker

EGB34015 - 15Amp Circuit Breaker

The EGB34015 Mini Circuit Breaker, is a top-tier solution for ensuring the safety and reliability of electrical systems in various applications. This miniature circuit breaker is part of the renowned E-Frame series by Schneider Electric, designed specifically for NF panelboards. It combines robust construction with advanced technology to provide superior protection against overloads and short circuits, making it an essential component in any electrical setup.

Key Features and Benefits:

• High Interrupt Rating: With a maximum interrupt rating of 65 kA at 120 VAC, this circuit breaker can handle substantial fault currents, ensuring the safety of your electrical systems.
• Thermal-Magnetic Trip Unit: Provides reliable protection by combining thermal (overload) and magnetic (short circuit) protection in a single unit.
• Durability: Engineered to last with a lifecycle of over 20 years, this breaker ensures long-term performance and reliability.
• Compatibility: Easily integrates with Square D NF panelboards, providing seamless installation and maintenance.
• HACR and HID Rated: Suitable for heating, air conditioning, refrigeration (HACR) applications, and high-intensity discharge (HID) lighting systems, making it versatile for various uses.

Technical Specifications:

• Amperage: 15A
• Poles: 3
• Voltage Rating: 480Y/277 VAC
• Interrupt Rating: 65 kA max at 120 VAC, 35 kA at 480Y/277 VAC
• Connection Type: Bolt-on with aluminum lugs
• Dimensions: Height 5.66 in (143.76 mm), Width 2.94 in (74.68 mm), Depth 4.05 in (102.87 mm)
• Weight: 4 lb (1.81 kg)
• Operating Temperature: Calibrated for 40å¡C ambient temperature

Material Compliance and Certifications:

• UL Listed: Ensures compliance with industry safety standards.
• RoHS and REACh Compliant: Meets global environmental regulations, free from hazardous substances.
• Green Premium‰ã¢ Label: Highlights Schneider Electric‰۪s commitment to delivering products with best-in-class environmental performance.

Suitability:

• The EGB34015 Mini Circuit Breaker is ideal for use in residential, commercial, and industrial environments. Its high interrupting capacity and reliable performance make it suitable for protecting circuits in lighting panelboards, HVAC systems, and other critical applications where safety and efficiency are paramount. Whether you are upgrading an existing system or installing new electrical infrastructure, this circuit breaker offers the peace of mind and performance you need.
