EGB3060FFB - 60Amp Circuit Breaker

EGB3060FFB - 60Amp Circuit Breaker

Keeping an existing electrical distribution system operating safely starts with using replacement components that match the original equipment. The EGB3060FFB Thermal Magnetic Circuit Breaker is a 60 Amp, 3-pole bolt-on molded case circuit breaker designed to provide the form, fit, and function required for compatible legacy electrical systems. Featuring fixed thermal magnetic trip settings, this breaker helps protect branch circuits from overloads and short circuits while maintaining the original configuration of your electrical equipment. Its bolt-on mounting design provides a secure installation, and the included load-side lug terminals help streamline wiring during maintenance or replacement projects.

Whether you're replacing a failed breaker or performing scheduled preventative maintenance, the EGB3060FFB is designed for use in compatible commercial and industrial electrical systems.

Key Features and Benefits

• 60 Amp current rating for branch circuit protection
• 3-pole configuration for compatible three-phase electrical systems
• Bolt-on mounting for secure installation in compatible equipment
• Thermal magnetic trip mechanism with fixed trip settings
• Helps protect electrical circuits from overloads and short circuits
• Includes load-side lug terminals for convenient field wiring
• Interrupting capacity of:
  • 25kA @ 240VAC
  • 18kA @ 480VAC
• Calibrated for operation in 40°C (104°F) ambient environments
• Designed to provide the form, fit, and function required for compatible legacy electrical systems
• Built to last for dependable service in properly maintained electrical equipment


Technical Specifications

• Part Number: EGB3060FFB

• Type: EGB Thermal Magnetic Circuit Breaker

• Current Rating: 60 Amps

• Number of Poles: 3

• Mounting Style: Bolt-On

• Trip Type: Thermal Magnetic with Fixed Trip Settings

• Interrupting Rating:
  • 25kA @ 240VAC
  • 18kA @ 480VAC
• Operating Temperature Calibration: 40°C (104°F)

• Terminals: Load-side lug terminals included

• Dimensions:
  • Height: 5.50 in.
  • Width: 3.00 in.
  • Depth: 2.94 in.
• Approximate Weight: 3 lbs.


Material Compliance and Certifications

The EGB3060FFB is manufactured for use in compatible molded case circuit breaker applications and is designed to meet applicable industry standards for electrical distribution equipment. Proper installation and maintenance should always follow applicable electrical codes and manufacturer recommendations to help ensure safe and dependable operation.

Where It Works Best

• Commercial office buildings
• Manufacturing and processing facilities
• Healthcare facilities
• Educational campuses
• Retail and mixed-use buildings
• Electrical distribution panels
• Control panels and switchgear
• Maintenance and retrofit projects
• Applications requiring a compatible 60 Amp, 3-pole bolt-on thermal magnetic circuit breaker
