EGB3020FFB - 20Amp Circuit Breaker

EGB3020FFB - 20Amp Circuit Breaker

When you're maintaining an existing electrical distribution system, selecting a breaker that's designed to match the original installation can help simplify the job. The EGB3020FFB Series G Molded Case Circuit Breaker is a 20-amp, 3-pole complete molded case circuit breaker built for applications requiring 600Y/347VAC operation. Designed to provide the form, fit, and function required for compatible electrical systems, this breaker is well-suited for commercial and industrial facilities where dependable circuit protection and compatibility are essential. Its line and load terminals allow for straightforward installation, while the T186 trip unit helps protect electrical circuits from overloads and short circuits, supporting the continued operation of your existing equipment.

Whether you're replacing a damaged breaker, performing preventative maintenance, or servicing an established electrical distribution system, the EGB3020FFB offers the ratings and compatibility needed to keep your project moving.

Key Features and Benefits

• 20 Amp current rating: for branch circuit protection
• 3-pole configuration: for compatible three-phase electrical systems
• Rated for 600Y/347VAC applications
• Complete molded case circuit breaker design
• T186 trip unit: helps protect against overloads and short circuits
• Line and load terminals: for straightforward installation
• Interrupting ratings of:
  • 25kAIC @ 240VAC
  • 18kAIC @ 480VAC
• Operates on 50/60 Hz electrical systems
• Designed for form, fit, and functional replacement in compatible equipment
• Built to last: for long-term service in existing electrical systems


Technical Specifications

• Catalog Number: EGB3020FFB

• Series: Series G

• Product Type: Complete Molded Case Circuit Breaker

• Circuit Breaker Type: EG

• Frame Type: EG Frame

• Rated Current: 20 Amps

• Number of Poles: 3

• Voltage Rating: 600Y/347VAC

• Trip Type: T186

• Frequency Rating: 50/60 Hz

• Interrupting Capacity:
  • 25kAIC @ 240VAC
  • 18kAIC @ 480VAC
• Terminals: Line and Load

• Dimensions:
  • Height: 5.5 in.
  • Width: 3.0 in.
  • Depth: 2.99 in.
• Weight: Approximately 3 lbs.


Material Compliance and Certifications

The EGB3020FFB is UL Listed, CSA Certified, IEC Rated, and CE Marked, meeting recognized industry standards for safety and compliance. It is intended for installation in compatible electrical systems and should be installed in accordance with applicable electrical codes and manufacturer specifications.

Where It Works Best

• Commercial office buildings
• Manufacturing and industrial facilities
• Healthcare facilities
• Schools and universities
• Retail and mixed-use buildings
• Electrical distribution equipment
• Control panels and switchgear
• Facility maintenance and retrofit projects
• Applications requiring a compatible 20-amp, 3-pole molded case circuit breaker
