EE2B100 - 100A Circuit Breaker

EE2B100 - 100A Circuit Breaker

When you need a 100 Amp, 2-pole Type EE2 molded case circuit breaker for an existing electrical system, the EE2B100 is designed to provide the correct form, fit, and function for compatible equipment. Whether you're replacing a breaker as part of scheduled maintenance or restoring a legacy electrical panel, selecting a breaker with matching specifications helps maintain the original design and operation of your electrical system.

Rated for 100 Amps with a 10 kA interrupting capacity at 240 VAC, the EE2B100 is intended to help protect electrical circuits from overloads and short circuits in compatible installations. Its molded case construction is built to last, while the Type EE2 frame is designed for equipment that requires this specific breaker configuration.

Key Features and Benefits

• 100 Amp current rating for compatible electrical systems
• Two-pole (2P) configuration
• Type EE2 molded case circuit breaker
• 10kA interrupting capacity at 240VAC
• Helps protect electrical circuits from overloads and short circuits
• Built to last for long-term use in compatible equipment
• Form, fit, and functional replacement for existing Type EE2 applications
• Calibrated for operation at 40°C (104°F)
• Compact molded case design for equipment requiring the Type EE2 frame

Technical Specifications

• Part Number: EE2B100

• Product Type: Molded Case Circuit Breaker

• Type: EE2

• Amperage: 100 Amps

• Poles: 2

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kA @ 240VAC

• Operating Temperature: 40°C (104°F)

• Dimensions:
  • Width: 3.00"
  • Height: 6.00"
  • Depth: 3.63"
• Approximate Shipping Weight: 4.00 lbs.


Material Compliance and Certifications

The EE2B100 is a molded-case circuit breaker designed for use in electrical systems requiring a Type EE2 breaker with matching electrical and physical specifications. It is calibrated for operation at 40°C (104°F) and should only be installed in equipment designed to accept this breaker type. Installation should be performed by qualified personnel in accordance with the National Electrical Code (NEC), applicable local electrical regulations, and the equipment manufacturer's recommendations. Always confirm compatibility before installation.

Where It Works Best

The EE2B100 is commonly used in electrical systems where maintaining compatibility with the original equipment is essential, including:

• Commercial buildings
• Industrial facilities
• Manufacturing equipment
• Electrical distribution panels
• Branch circuit protection
• Equipment maintenance and repair
• Existing legacy electrical systems
• OEM equipment designed for Type EE2 circuit breakers
