EE2B090 - 90Amp Circuit Breaker

EE2B090 - 90Amp Circuit Breaker

When you need a 90 Amp, 2-pole Type EE2 molded case circuit breaker for an existing electrical system, the EE2B090 is designed to provide the correct form, fit, and function for compatible equipment. Whether you're replacing a worn breaker during routine maintenance or restoring a legacy electrical panel, choosing the correct breaker helps keep your system operating as originally designed.

Rated at 90 Amps with a 10 kA interrupting capacity at 240 VAC, the EE2B090 helps protect electrical circuits against overloads and short circuits in compatible installations. Its molded-case construction is built to last, while the compact Type EE2 frame is designed to fit equipment that requires this breaker style. Calibrated for 40°C (104°F) operation, it meets the requirements of many commercial and industrial electrical applications where matching the original equipment specifications is essential.

Key Features and Benefits

• 90 Amp current rating for compatible electrical systems
• Two-pole (2P) configuration
• Type EE2 molded case circuit breaker
• 10kA interrupting capacity at 240VAC
• Helps protect circuits from overloads and short circuits
• Built to last for long-term use in compatible equipment
• Form, fit, and functional replacement for existing Type EE2 applications
• Calibrated for operation at 40°C (104°F)
• Compact molded case design for equipment requiring the Type EE2 frame

Technical Specifications

• Part Number: EE2B090

• Product Type: Molded Case Circuit Breaker

• Type: EE2

• Amperage: 90 Amps

• Poles: 2

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kA @ 240VAC

• Operating Temperature: 40°C (104°F)

• Dimensions:
  • Width: 3.00"
  • Height: 6.00"
  • Depth: 3.63"
• Approximate Shipping Weight: 4.00 lbs.


Material Compliance and Certifications

The EE2B090 is a molded-case circuit breaker designed for use in electrical systems requiring a Type EE2 breaker with matching electrical and physical specifications. It is calibrated for operation at 40°C (104°F) and should only be installed in equipment designed to accept this breaker type. Installation should be completed by qualified personnel in accordance with the National Electrical Code (NEC), applicable local regulations, and the equipment manufacturer's recommendations. Always verify compatibility before installation.

Where It Works Best

• The EE2B090 is commonly used in electrical systems where maintaining compatibility with the original equipment is important, including:
• Commercial buildings
• Industrial facilities
• Manufacturing equipment
• Electrical distribution panels
• Branch circuit protection
• Equipment maintenance and repair
• Existing legacy electrical systems
• OEM equipment designed for Type EE2 circuit breakers
