EE2B070 - 70A Circuit Breaker

EE2B070 - 70A Circuit Breaker

When you need a replacement circuit breaker that matches your existing electrical system, the EE2B070 molded case circuit breaker offers the form, fit, and function required for compatible equipment. Designed as a 70 Amp, 2-pole Type EE2 breaker, it helps protect electrical circuits from overloads and short circuits while maintaining the original design of the system it's intended for.

Whether you're performing scheduled maintenance, replacing a failed breaker, or keeping older equipment operating as designed, selecting the correct replacement is essential. The EE2B070 features a 10kA interrupting rating at 240VAC and is calibrated for operation at 40°C (104°F), making it suitable for electrical systems built around these specifications. Its molded case construction is built to last, while its compact footprint allows it to fit equipment designed specifically for the Type EE2 frame.

Key Features and Benefits

• 70 Amp current rating for compatible electrical distribution systems
• Two-pole (2P) configuration
• Type EE2 molded case circuit breaker
• 10kA interrupting capacity at 240VAC
• Helps protect circuits against overloads and short circuits
• Built to last for long-term use in compatible equipment
• Form, fit, and functional replacement for systems designed for Type EE2 breakers
• Calibrated for operation at 40°C (104°F)
• Compact dimensions for equipment requiring the Type EE2 frame

Technical Specifications

• Part Number: EE2B070

• Product Type: Molded Case Circuit Breaker

• Type: EE2

• Amperage: 70 Amps

• Poles: 2

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kA @ 240VAC

• Operating Temperature: 40°C (104°F)

• Dimensions:
  • Width: 3.00"
  • Height: 6.00"
  • Depth: 3.63"
• Approximate Shipping Weight: 4.00 lbs.


Material Compliance and Certifications

The EE2B070 is a molded-case circuit breaker designed for electrical systems requiring a Type EE2 breaker with matching electrical and physical characteristics. It is calibrated for operation at 40°C (104°F) and should only be installed in equipment designed for this breaker type. Installation should be performed by qualified personnel in accordance with the National Electrical Code (NEC), applicable local electrical codes, and the equipment manufacturer's recommendations. Always verify compatibility before installation.

Where It Works Best

The EE2B070 is commonly used in electrical systems that require a 70 Amp, 2-pole Type EE2 molded case circuit breaker, including:

• Commercial buildings
• Industrial facilities
• Manufacturing equipment
• Electrical distribution panels
• Branch circuit protection
• Maintenance and repair projects
• Existing legacy electrical systems
• OEM equipment designed for Type EE2 circuit breakers
