EE2B040 - 40A Circuit Breaker

EE2B040 - 40A Circuit Breaker

The EE2B040 is a 40 Amp, 2-pole molded case circuit breaker designed as a form, fit, and functional replacement for compatible electrical distribution equipment that uses Type EE2 circuit breakers. When maintaining or repairing existing electrical systems, selecting a breaker that matches the original electrical ratings and physical dimensions is essential to preserve compatibility and minimize changes to the installation. This breaker is built to last and is intended for use in applications where the original equipment calls for a 40 Amp, 2-pole breaker with a 10kA interrupting capacity at 240VAC. Calibrated for operation at 40°C (104°F), the EE2B040 provides dependable circuit protection against overloads and short circuits in compatible systems. As with any replacement breaker, verify that the part number, amperage, voltage, interrupting capacity, pole configuration, and dimensions match your equipment specifications before installation.

Key Features and Benefits

• 40 Amp current rating for compatible branch circuit protection
• Two-pole (2P) configuration
• Type EE2 molded case circuit breaker
• 10kA interrupting capacity at 240VAC
• Helps protect electrical circuits from overloads and short circuits
• Built to last for continued use in compatible electrical systems
• Form, fit, and functional replacement for equipment designed for Type EE2 circuit breakers
• Calibrated for operation at 40°C (104°F)
• Compact size helps simplify replacement in equipment requiring matching dimensions

Technical Specifications

• Part Number: EE2B040

• Product Type: Molded Case Circuit Breaker

• Type: EE2

• Amperage: 40 Amps

• Poles: 2

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kA @ 240VAC

• Operating Temperature: 40°C (104°F)

• Dimensions:
  • Width: 3.00"
  • Height: 6.00"
  • Depth: 3.63"
• Approximate Shipping Weight: 4.00 lbs.


Material Compliance and Certifications

The EE2B040 is a molded case circuit breaker designed for use in electrical systems that require a Type EE2 breaker with matching electrical ratings and physical dimensions. It is calibrated for operation at 40°C (104°F) and should be installed only in equipment designed to accommodate this breaker type. Installation should be completed by qualified personnel in accordance with the National Electrical Code (NEC), the original equipment manufacturer's installation requirements, and all applicable local electrical codes. Verifying compatibility before installation helps support proper operation within the intended electrical system.

Where It Works Best

• Commercial electrical systems
• Industrial facilities
• Manufacturing equipment
• Electrical distribution panels
• Branch circuit protection
• Facility maintenance and repair projects
• Existing legacy electrical systems
• Compatible OEM equipment designed for Type EE2 circuit breakers
