EE2B020 - 20A Circuit Breaker

EE2B020 - 20A Circuit Breaker

When you need a 20 Amp, 2-pole molded case circuit breaker that matches the specifications of an existing Type EE2 installation, the EE2B020 is designed to provide the correct form, fit, and function for compatible electrical systems. Whether you're replacing a worn breaker during scheduled maintenance or servicing an existing distribution panel, choosing the correct replacement helps maintain the integrity of the electrical system without requiring unnecessary modifications.

Built to last, the EE2B020 is rated for 20 Amps with a 10kA interrupting capacity at 240VAC, providing dependable protection against overloads and short circuits in compatible applications. Its compact footprint and 40°C calibration make it suitable for installations where matching the original electrical and physical specifications is essential.

Key Features and Benefits

• 20 Amp current rating for dependable branch circuit protection
• Two-pole (2P) configuration
• Type EE2 molded case circuit breaker
• 10kA interrupting capacity at 240VAC
• Designed to help protect circuits from overloads and short circuits
• Built to last for continued service in compatible electrical systems
• Form, fit, and functional replacement for equipment designed for Type EE2 breakers
• Calibrated for operation at 40°C (104°F)
• Compact design for installations requiring matching dimensions

Technical Specifications

• Part Number: EE2B020

• Product Type: Molded Case Circuit Breaker

• Type: EE2

• Amperage: 20 Amps

• Poles: 2

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kA @ 240VAC

• Operating Temperature: 40°C (104°F)

• Dimensions:
  • Width: 3.00"
  • Height: 6.00"
  • Depth: 3.63"
• Approximate Shipping Weight: 4.00 lbs.


Material Compliance and Certifications

The EE2B020 is a molded case circuit breaker intended for use in electrical systems requiring a Type EE2 breaker with matching electrical ratings and physical dimensions. It is calibrated for operation at 40°C (104°F) and should be installed only in equipment designed to accept this breaker type. Installation should always be performed by qualified personnel in accordance with the National Electrical Code (NEC), the equipment manufacturer's instructions, and all applicable local electrical codes. Confirm compatibility before installation to help ensure proper operation.

Where It Works Best

• Commercial buildings
• Industrial facilities
• Manufacturing equipment
• Electrical distribution panels
• Branch circuit protection
• Facility maintenance and repair projects
• Existing legacy electrical systems
• Compatible OEM equipment designed for Type EE2 circuit breakers
