EE1B020 - 20Amp Circuit Breaker

EE1B020 - 20 Amp Circuit Breaker

Ensure your electrical system maintains reliable operation with the EE1B020 molded case circuit breaker. Designed for form, fit, and functional replacement in legacy EE1 frame panels, this single-pole 20-amp breaker is rated for 120 volts AC with a 10kA interrupting capacity. Built to meet industry standards, it provides consistent protection against overloads and short circuits, helping maintain safe and efficient power distribution. Lightweight and compact, it’s an ideal choice for residential, commercial, and light industrial applications where dependable circuit protection is essential.

Key Features and Benefits

• Single-Pole Configuration: Simplifies installation in EE1 frame panels.
• 20 Amp Rating: Supports typical branch circuits in homes and small commercial setups.
• 10kA Interrupting Capacity @ 120VAC: Safely handles fault currents within its rating.
• Compact & Lightweight: At only 1.5 lbs, it’s easy to handle and install.
• Molded Case Design: Provides secure electrical protection while ensuring proper fit in compatible panels.

Technical Specifications

• Part Number: EE1B020
• Poles: 1
• Amperes: 20
• Voltage Rating: 120VAC
• Interrupting Capacity: 10kA
• Frame Type: EE1
• Weight: 1.5 lbs
• Height: 6.0 inches
• Temperature Rating: 40°C

Material Compliance and Certifications

• Constructed to meet UL 489 standards for circuit breakers.
• Molded case provides insulation and protection against environmental factors.
• Meets material compliance requirements for safe electrical applications.

Where It Works Best

• The EE1B020 is ideal for replacing single-pole breakers in EE1 frame panels in residential and commercial electrical systems. It’s suitable for branch circuits powering lighting, outlets, and small appliances, and works seamlessly in retrofit or maintenance scenarios requiring reliable, code-compliant circuit protection.
