EDB34080 - 80Amp Circuit Breaker

EDB34080 - 80Amp Circuit Breaker

Introducing the EDB34080 Mini Circuit Breaker, a premium solution for your electrical protection needs. Designed by Schneider Electric, this high-performance circuit breaker ensures robust protection and reliability for low-voltage electronics. Ideal for commercial and industrial applications, the EDB34080 is a crucial component for any lighting panelboard setup, offering superior overload and short-circuit protection.

Key Features and Benefits:

• High Current Rating: The EDB34080 offers an 80A current rating, making it suitable for demanding electrical systems.
• Triple Pole Design: With its 3-pole configuration, this circuit breaker provides comprehensive protection and reliability.
• Voltage Compatibility: Operates efficiently at 480Y/277 VAC, ensuring versatility across various electrical installations.
• Durability: Engineered to last for up to 20 years, offering long-term reliability and peace of mind.
• High Interrupt Rating: Capable of handling up to 25 kA at 120 VAC, ensuring safety and protection in high fault conditions.
• HACR Rated: Suitable for heating, air conditioning, and refrigeration applications, providing versatility in usage.

Technical Specifications:

• Range of Product: 125 A Frame EDB-EGB-EJB
• Device Short Name: EDB
• Trip Unit Rating: 2300 A
• Line Rated Current: 80 A
• Maximum Operating Voltage: 480Y/277 V AC
• AWG Gauge: Supports AWG 12...AWG 2/0 aluminum and AWG 14...AWG 2/0 copper
• Breaking Capacity: 18 kA at 277 V AC, 25 kA at 240 V AC, 18 kA at 480Y/277 V AC, and 25 kA at 120/240 V AC
• Mounting Mode: Bolt-on
• Number of Poles: 3
• Dimensions: Height: 5.66 in (143.76 mm), Width: 2.94 in (74.68 mm), Depth: 4.05 in (102.87 mm)
• Weight: 4 lb (1.81 kg)

Material Compliance and Certifications:

• Certifications: cULus certified, ensuring compliance with industry standards for safety and performance.
• Environmental Compliance: Green Premium‰ã¢ label, signifying Schneider Electric's commitment to sustainability and environmental performance. The breaker is mercury-free and compliant with RoHS regulations.
• Sustainability: Designed with a focus on reducing environmental impact, this product supports circular economy principles and low CO2 emissions.

Suitability:

• The EDB34080 Mini Circuit Breaker is ideally suited for use in Square D NF Panelboards, making it perfect for a range of commercial and industrial applications. Its robust design and advanced features make it an excellent choice for protecting low-voltage electronics, ensuring safety and reliability in your electrical systems. Whether you need protection for lighting panelboards or require a durable and efficient circuit breaker for HACR applications, the EDB34080 is the go-to solution.
