EDB34070 - 70Amp Circuit Breaker

EDB34070 - 70Amp Circuit Breaker

Introducing the EDB34070 Circuit Breaker, a high-performance miniature circuit breaker designed for superior protection and reliability in lighting panelboards. Engineered by Schneider Electric, this E-Frame breaker offers an impressive 70-amp, 3-pole configuration with a voltage rating of 480Y/277 VAC. The EDB34070 is an essential component for safeguarding low-voltage electronics in commercial and industrial settings, ensuring both safety and efficiency.

Key Features and Benefits:

• High Interrupt Rating: Boasts a maximum interrupt capacity of 25 kA at 120 VAC, offering robust protection against overloads and short circuits, essential for high-demand environments.
• Bolt-On Mount: Designed for easy installation in Square D NF panelboards, ensuring a secure and reliable connection that enhances overall system stability.
• Durability: Engineered to last with a 20-year lifespan, providing long-term reliability and reducing the need for frequent replacements.
• Thermal-Magnetic Trip Unit: Combines thermal and magnetic trip functions to provide precise protection tailored to specific applications, preventing damage to electrical systems.

Technical Specifications:

• Range of Product: 125 A Frame EDB-EGB-EJB
• Device Short Name: EDB
• Module Type: E-Frame
• Line Rated Current: 70 A
• Maximum Operating Voltage: 480Y/277 V AC
• Breaking Capacity: 25 kA at 120 VAC, 18 kA at 480Y/277 VAC
• Electrical Connection: Lugs aluminum
• Holding Current: 630 A
• Trip Unit Rating: 1800 A
• Mounting Mode: Bolt-on
• Number of Poles: 3
• Product Dimensions: Height: 5.66 in, Width: 2.94 in, Depth: 4.05 in
• Net Weight: 4 lb (1.81 kg)

Material Compliance and Certifications:

• Certifications: cULus certified, ensuring compliance with industry standards for safety and performance.
• Green Premium Label: Demonstrates Schneider Electric's commitment to sustainability, offering products with best-in-class environmental performance, compliance with the latest regulations, and low-CO2 footprint.
• RoHS Compliance: Pro-active compliance with EU and China RoHS directives, ensuring that the product is free from harmful substances.

Suitability:

• The EDB34070 Circuit Breaker is ideally suited for use in lighting panelboards, specifically within commercial and industrial environments that require reliable low-voltage protection. Its robust features and compliance with industry standards make it an excellent choice for new installations or upgrades in existing electrical systems. efficiency, ensuring the safety and performance of your electrical infrastructure.
