EDB34035 - 35A Circuit Breaker

EDB34035 35A Circuit Breaker

The EDB34035 is a high-performance miniature circuit breaker designed to deliver exceptional protection for low-voltage electronic systems. Ideal for use in lighting panelboards, this E-Frame circuit breaker boasts a robust 35A, 3-pole configuration with an operating voltage of 480Y/277 VAC. Its bolt-on mounting ensures a secure installation, making it a reliable component in any electrical setup. With a maximum interrupting rating of 25 kA at 120 VAC, the EDB34035 effectively safeguards your circuits against overloads and short circuits, enhancing the safety and longevity of your electrical infrastructure.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Provides reliable protection by automatically disconnecting the circuit when it detects overloads or short circuits.
• Compatibility: Specifically designed to fit NF panelboards, ensuring seamless integration and reliable performance.
• Durability: Engineered for a lifespan of up to 20 years, offering long-term reliability and peace of mind.
• HID and HACR Rated: Suitable for high-intensity discharge lighting and heating, air conditioning, and refrigeration equipment applications, providing versatile usage across different systems.

Technical Specifications:

• Frame Type: E-Frame
• Current Rating: 35 Amperes
• Poles: 3
• Voltage Rating: 480Y/277 VAC
• Interrupting Rating: 25 kA max at 120 VAC
• Mounting Style: Bolt-on
• Dimensions: Height: 5.66 in, Width: 2.94 in, Depth: 4.05 in
• Weight: 4 lb (1.81 kg)
• Temperature Calibration: 40å¡C

Material Compliance and Certifications:

• Compliance: The EDB34035 circuit breaker is crafted with high-quality materials to ensure optimal performance and compliance with safety standards. It holds a cULus certification, guaranteeing adherence to stringent safety regulations. Additionally, this product is mercury-free and meets the RoHS and REACh regulations, reflecting Schneider Electric‰۪s commitment to environmental sustainability and responsible manufacturing practices.

Suitability:

• This circuit breaker is ideally suited for commercial and industrial applications where dependable circuit protection is critical. Its HID and HACR ratings make it an excellent choice for lighting systems and HVAC equipment. Whether you‰۪re upgrading an existing panelboard or setting up a new installation, the EDB34035 offers the reliability and performance you need to keep your systems running smoothly.
