EDB34030 - 30A Circuit Breaker

EDB34030 30A Circuit Breaker

Introducing the EDB34030 Mini Circuit Breaker, a high-performance and reliable solution designed to protect low-voltage electronics in lighting panelboards. Manufactured by Schneider Electric, this circuit breaker combines robust features with cutting-edge technology to ensure superior performance and safety in various electrical applications. With its compact E-Frame design, the EDB34030 is specifically engineered for easy bolt-on installation in Square D NF panelboards, making it an ideal choice for commercial and industrial environments.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Features a thermal-magnetic trip unit that ensures precise overload and short-circuit protection, enhancing the safety of your electrical systems.
• HID and HACR Rated: This breaker is HID (High-Intensity Discharge) and HACR (Heating, Air Conditioning, and Refrigeration) rated, ensuring compatibility with a wide range of lighting and HVAC applications.
• Durability: Built to last with a lifespan of up to 20 years, providing long-term reliability and peace of mind.

Technical Specifications:

• Current Rating: 30 Amperes
• Poles: 3
• Operating Voltage: 480Y/277 VAC
• Interrupting Capacity: 25 kA at 120 VAC, 18 kA at 480Y/277 VAC
• Trip Current: 875 Amperes
• Holding Current: 270 Amperes
• Dimensions: Height 5.66 inches, Width 2.94 inches, Depth 4.05 inches
• Mounting: Bolt-on

Material Compliance and Certifications:

• UL Listed: Certified by Underwriters Laboratories (UL) for safety and performance.
• Green Premium‰ã¢ Label: Compliant with Schneider Electric‰۪s Green Premium‰ã¢ environmental standards, ensuring low CO2 emissions, transparency on environmental impacts, and sustainability.
• RoHS: Proactively compliant with the EU RoHS Directive, ensuring the product is free from hazardous substances.
• REACh Regulation: Adheres to the REACh Regulation, providing a declaration of the presence of substances of very high concern.

Suitability:

• The EDB34030 Mini Circuit Breaker is ideally suited for use in lighting panelboards within commercial, industrial, and institutional facilities. Its high interrupting capacity and advanced features make it a reliable choice for protecting low-voltage electronic circuits against overloads and short circuits. Additionally, its compatibility with a range of accessories and its robust design ensure it meets the demanding requirements of modern electrical installations.

The EDB34030 Mini Circuit Breaker offers unmatched protection and performance for your electrical systems. Whether you're managing commercial lighting or industrial circuits, its advanced safety features and easy installation make it a trusted choice for modern applications.
