EDB34025 - 25Amp Circuit Breaker

EDB34025 - 25Amp Circuit Breaker

Elevate the safety and efficiency of your electrical systems with the EDB34025 Miniature Circuit Breaker. This robust E-Frame, 25 Amp, 3-pole circuit breaker is designed to handle a maximum operating voltage of 480Y/277 VAC and an impressive 25 kA interrupt rating, ensuring reliable performance in even the most demanding environments. Its bolt-on design makes installation straightforward, integrating seamlessly with Square D NF Panelboards to provide superior overload and short-circuit protection for your low-voltage electronics.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Combines thermal and magnetic protection mechanisms to safeguard against both overloads and short circuits.
• HID and HACR Rated: Ideal for high-intensity discharge lighting and heating, air conditioning, and refrigeration applications, ensuring versatile use across various settings.
• Durable Construction: Engineered to last up to 20 years, providing long-term reliability and peace of mind.
• High Breaking Capacity: With up to 25 kA max interrupt rating at 120 VAC, it can handle significant fault currents, protecting your system from severe damage.

Technical Specifications:

• Amperage: 25A
• Poles: 3
• Voltage: 480Y/277 VAC
• Interrupt Rating: 25 kA at 120 VAC
• Hold Current: 270A
• Trip Current: 875A
• Dimensions: Height 5.66 in (143.76 mm), Width 2.94 in (74.68 mm), Depth 4.05 in (102.87 mm)
• Weight: 4 lbs (1.81 kg)
• Connection: Bolt-on with aluminium lugs

Material Compliance and Certifications:

• UL Listed: Meets stringent safety and performance standards.
• RoHS Compliant: Free from hazardous substances, adhering to global environmental regulations.
• Green Premium‰ã¢ Label: Part of Schneider Electric‰۪s commitment to sustainability, offering best-in-class environmental performance.

Suitability:

• The EDB34025 circuit breaker is specifically designed for use in Square D NF Panelboards, making it an optimal choice for commercial and industrial lighting applications. Its HID and HACR ratings ensure it is suitable for a variety of lighting and HVAC systems, while its durable design and high interrupting capacity make it ideal for protecting critical low-voltage electronics in demanding environments.
