EDB34020 - 20A Circuit Breaker

EDB34020 20A Circuit Breaker

The EDB34020 Circuit Breaker is your ultimate solution for superior overload and short circuit protection. Designed for reliability and efficiency, this 20A, 3-pole miniature circuit breaker is a crucial component for lighting panelboards, specifically tailored for Square D NF panelboards. With a robust construction and advanced features, the EDB34020 ensures maximum safety and longevity, making it ideal for protecting low-voltage electronics.

Key Features and Benefits:

• Bolt-on Mount Design: Ensures a secure and easy installation, perfectly fitting NF panelboards.
• Thermal-Magnetic Trip Unit: Provides precise overload and short circuit protection, ensuring safety and reliability.
• HID and HACR Rated: Suitable for high-intensity discharge lighting and heating, air conditioning, and refrigeration applications.
• Durable Construction: Built to last with a lifespan of up to 20 years, ensuring long-term performance and dependability.

Technical Specifications:

• Current Rating: 20A
• Number of Poles: 3
• Voltage Rating: 480Y/277 VAC
• Interrupt Rating: Up to 25 kA at 120 VAC
• Trip Current: 875A
• Holding Current: 270A
• Dimensions: Height - 5.66 in, Width - 2.94 in, Depth - 4.05 in
• Weight: 4 lb (1.81 kg)
• Mounting Mode: Bolt-on
• Local Signaling: Trip indicator

Material Compliance and Certifications:

• UL Listed: Meets high-intensity discharge (HID) standards.
• Green Premium‰ã¢ Label: Ensures compliance with environmental regulations, providing transparency on environmental impacts and promoting sustainability.
• RoHS and REACh Compliant: Adheres to the latest regulations for hazardous substances, ensuring safe and eco-friendly usage.
• Mercury-Free: Supports environmental health and safety.

Suitability:

• The EDB34020 Circuit Breaker is an excellent choice for commercial and industrial applications, particularly in settings where reliable protection of low-voltage electronics is paramount. Its compatibility with NF panelboards and its robust design make it ideal for use in lighting panelboards, HVAC systems, and other critical infrastructure requiring high-intensity discharge lighting and heating, air conditioning, and refrigeration.
