EDB34015 - 15 Amp Circuit Breaker

EDB34015 - 15 Amp Circuit Breaker

This 15 Amp Mini Circuit Breaker is built to give you dependable protection for your electrical systems — whether you're managing lighting panels, HVAC units, or HID lighting circuits in commercial and industrial settings. Compact yet powerful, it delivers effective overload and short-circuit defense, helping you safeguard equipment, reduce downtime, and maintain compliance with modern safety and environmental standards.

Key Features and Benefits

• Thermal‑Magnetic Trip Unit: The breaker uses a dual-action trip mechanism: the magnetic element reacts instantly to short circuits, while the thermal side responds to sustained overloads. This combination ensures fast, accurate protection, preserving system integrity and safety.
• HACR & HID Rated: Designed for versatility, the breaker is HACR‑rated (heating, air conditioning, and refrigeration) and HID‑rated (high‑intensity discharge lighting). That makes it a flexible choice across varied applications — from air‑conditioning systems to warehouse lighting and beyond.
• Durable, Long‑Lasting Construction: Engineered for a long service life — up to 20 years under normal conditions — this unit is built for dependability and minimal replacement frequency. The sturdy design helps you avoid frequent maintenance or unexpected replacements.
• Bolt‑On Mounting for Easy Installation: Installing this breaker is straightforward: the bolt‑on mounting design fits neatly into compatible panelboards (such as Square D NF panels), eliminating the hassle associated with loose bus stabs or complicated setups. Just bolt it in — no extra parts, no extra time.

Technical Specifications

• Rated Current: 15 A
• Operating Voltage: 480Y/277 VAC
• Interrupting Capacity:
  • 25 kA @ 120 VAC
  • 18 kA @ 480Y/277 VAC
• Trip‑Unit Rating: 875 A magnetic threshold
• Holding Current: 270 A
• Dimensions (HxWxD):
  • 5.66″ × 2.94″ × 4.05″ (143.8 × 74.7 × 102.9 mm)
• Weight: Approx. 4 lb (1.8 kg)
• Certifications: UL listed • cULus certified

Material Compliance and Certifications

• Green Premium™ Environmental Label: This circuit breaker carries the Green Premium™ environmental label, signifying that it is mercury‑free and compliant with REACH and RoHS standards.
• Eco-Friendly Manufacturing: Its manufacturing process is optimized for lower CO₂ emissions — an ideal choice for eco-conscious projects or businesses with sustainability goals.
• Regulatory Compliance: With full UL and cULus certification, you get both safety assurance and regulatory compliance.

Where It Works Best

• Lighting Panelboards: Ideal for overhead or emergency lighting systems in commercial or institutional buildings.
• HVAC & Refrigeration Systems: HACR‑rated design makes it a reliable match for heating, ventilation, air‑conditioning, and refrigeration units.
• HID Lighting Circuits: Great for high‑intensity discharge lighting applications, such as warehousing, stadiums, or street lighting installations.
• Commercial & Industrial Electrical Installations: Whether you’re upgrading existing infrastructure or working on new builds, this breaker provides dependable performance for a variety of low‑voltage uses.
