EDB24125 - 125A Circuit Breaker

EDB24125 125A Circuit Breaker

Introducing the EDB24125 Miniature Circuit Breaker, a robust and reliable solution for your electrical protection needs. This top-tier circuit breaker is specifically designed for use in lighting panelboards, offering superior performance and unparalleled reliability.

Key Features and Benefits:

• High Capacity and Durability: With a rating of 125A and a maximum voltage of 480Y/277VAC, this 2-pole circuit breaker ensures robust protection for your electrical systems. It boasts a high interrupting capacity of 25kA, providing excellent protection against overloads and short circuits.
• Thermal-Magnetic Trip Unit: This E-frame circuit breaker features a thermal-magnetic trip unit, offering precise and reliable protection against overloads and short circuits, ensuring the safety of your low-voltage electronics.
• Bolt-On Mounting: The bolt-on mounting design allows for easy installation directly onto NF panelboards, providing a secure and stable connection.

Technical Specifications:

• Amperage: 125A
• Poles: 2
• Voltage: 480Y/277VAC
• Interrupt Rating: 25kA at 120VAC
• Dimensions: Height: 5.66 in (143.76 mm), Width: 1.96 in (49.78 mm), Depth: 4.05 in (102.87 mm)
• Weight: 3 lb (1.36 kg)
• Material Compatibility: Suitable for use with AWG 12 to AWG 2/0 aluminium and AWG 14 to AWG 2/0 copper wires.

Material Compliance and Certifications:

• Certifications: cULus listed, ensuring compliance with industry safety standards.
• Environmental Standards: This product is RoHS compliant, mercury-free, and meets the requirements of the REACh Regulation and the EU RoHS Directive, promoting environmental sustainability.

Suitability:

• The EDB24125 is ideal for protecting low-voltage electronics in residential, commercial, and industrial lighting panelboards. Its robust construction and advanced features make it a perfect choice for ensuring the safety and longevity of your electrical systems.
