EDB24100 - 100 Amp Circuit Breaker

EDB24100 - 100 Amp Circuit Breaker

The EDB24100 Mini Circuit Breaker is a dependable, high‑performance 100 Amp breaker engineered for low‑voltage electrical systems. Whether you’re outfitting a lighting panelboard, setting up HVAC controls, or outfitting a commercial or industrial facility, this unit delivers consistent protection and long-term reliability. It’s a solid choice for anyone who wants safety and performance wrapped into one compact device.

Key Features and Benefits

• High interrupting capacity (25 kA): Offers strong protection against overloads and short circuits, giving you peace of mind that connected equipment stays safe.
• Thermal‑magnetic trip unit: Ensures accurate circuit interruption under overload or fault conditions — protecting your wiring and devices from damage.
• HACR rated: Ready for use with heating, air conditioning, and refrigeration equipment — ideal for commercial HVAC setups, office buildings, or retail spaces.
• Long service life: Designed to deliver dependable performance for up to 20 years, reducing maintenance and replacement needs over time.
• Bolt‑on mounting: Allows secure and straightforward installation directly onto NF panelboards — saving you time and effort during setup.

Technical Specifications

• Current Rating: 100 A
• Number of Poles: 2
• Operating Voltage: 480Y/277 V AC
• Interrupting Rating: 25 kA max @ 120 V AC
• Holding Current: 1000 A
• Trip Current: 2300 A
• Dimensions (HxWxD): 5.66 in × 1.96 in × 4.05 in (143.76 mm × 49.78 mm × 102.87 mm)
• Weight: 3 lb (1.36 kg)
• Mounting Mode: Bolt-on
• Connection Type: Lugs, Aluminum/Copper compatible

Material Compliance and Certifications

• Certifications: This breaker meets strict safety and environmental requirements. It comes with cULus certification, ensuring it conforms to recognized standards for electrical safety in the U.S.
• Environmental Compliance: It carries a Green Premium–equivalent designation, which signifies that it’s free from harmful substances like mercury and meets leading ecological standards, including RoHS, REACh, and other environmental compliance regulations.

Where It Works Best

• The EDB24100 is ideal for installation in NF-style lighting panelboards, making it a go‑to for commercial lighting systems. Its HACR rating allows use with HVAC equipment — perfect for retail stores, offices, restaurants, warehouses, or any building needing reliable heating, ventilation, or refrigeration circuits.
• This breaker is also well suited to industrial or institutional settings where dependable, long-term circuit protection matters most. If you’re an electrician, contractor, or building manager looking for a dependable, versatile, and environmentally aware mini circuit breaker — this is a top option.
