EDB24090 - 90 Amp Circuit Breaker

EDB24090 - 90 Amp Circuit Breaker

Meet the EDB24090 Mini Circuit Breaker — a dependable 90 A, 2‑pole protection device from Schneider Electric designed to give commercial and industrial electrical systems the high‑capacity safety they deserve. Whether you are wiring a lighting panelboard or powering heavy-duty equipment, this breaker delivers dependable overload and short‑circuit protection, ensuring your system remains secure and operational even under demanding conditions.

Key Features and Benefits

• High‑capacity protection: With a 90 A rating and 2‑pole configuration, the EDB24090 handles both overload and short‑circuit scenarios with ease. Its thermal‑magnetic trip unit and 25 kA maximum interrupting rating ensure it can safely interrupt high fault currents.
• Reliable performance under load: Calibrated to operate effectively at 40 °C and HACR-rated for heating, air conditioning, and refrigeration loads, this breaker delivers continuous, heavy-duty performance without compromise.
• Easy installation and monitoring: The bolt-on mounting design simplifies installation, and the built-in trip indicator makes status checks quick and easy — no guesswork required.
• Seamless compatibility: Purposefully engineered for use with Square D NF Panelboards, the EDB24090 integrates smoothly into existing panelboard systems for a clean, professional setup.

Technical Specifications

• Product Series / Frame: 125 A Frame (EDB‑EGB‑EJB series)
• Device Short Name: EDB
• Trip Unit: Thermal-magnetic unit, 2300 A rating
• Line Rated Current: 90 A
• Voltage Rating: 480Y/277 V AC
• Interrupting Capacity:
  • 25 kA at 240 V AC
  • 18 kA at 277 V AC
  • 18 kA at 480Y/277 V AC
  • 25 kA at 120 V AC
• Poles: 2
• Dimensions:
  • Height: 5.66 in
  • Width: 1.96 in
  • Depth: 4.05 in
• Weight: 3 lb (approx. 1.36 kg)
• Mounting Mode: Bolt-on

Material Compliance and Certifications

• Safety certified: cULus certification ensures compliance with stringent North American safety and quality standards.
• Eco-conscious manufacturing: Carries the Green Premium label, confirming it is mercury‑free, RoHS compliant, and meets REACh requirements for environmental safety.
• Sustainability built in: Designed and manufactured to reduce environmental impact without sacrificing performance or durability.

Where It Works Best

• The EDB24090 Mini Circuit Breaker is ideal for commercial and industrial settings where dependable electrical protection is non‑negotiable. It’s especially well-suited for lighting panelboards, HVAC systems, and other heavy-load circuits demanding reliable overload and short‑circuit protection. If you’re seeking a breaker that combines long-lasting performance with safety and compliance, this unit is a wise, future‑ready choice that keeps your installations both secure and efficient.
