EDB24080 - 80 Amp Circuit Breaker

EDB24080 - 80 Amp Circuit Breaker

Engineered for reliable protection of low-voltage electrical systems, the EDB24080 80 A circuit breaker is a dependable choice for safeguarding lighting panelboards, control circuits, and other essential electrical loads. With a two-pole design and a 480Y/277 VAC rating, this breaker delivers consistent performance and dependable safety for both commercial and light industrial settings. Whether you're upgrading an existing setup or wiring a new panelboard, the EDB24080 helps ensure that overloads and short circuits are managed before they become a problem — giving you peace of mind that your system is well protected.

Key Features and Benefits

• Thermal‑Magnetic Trip Unit: Precisely monitors current flow to provide accurate overload and short-circuit protection, enhancing the safety and lifespan of connected equipment.
• Bolt-On Mounting: Designed for straightforward installation in NF-type panelboards, the bolt-on design ensures stability and a secure fit.
• High Interrupt Rating: With a maximum interrupting capacity of 25 kA at 120 VAC (and 18 kA at 480Y/277 VAC), the EDB24080 offers strong protection against electrical faults, minimizing risk to your wiring and attached devices.
• Wide Compatibility: Works with a broad range of panelboard accessories, offering versatility so you can tailor the breaker to your particular setup and needs.

Technical Specifications

• Rated Current: 80 A
• Operating Voltage: 480Y / 277 VAC
• Interrupt Rating:
  • 25 kA max at 120 VAC
  • 18 kA at 480Y/277 VAC
• Poles: 2 (two-pole)
• Mounting Type: Bolt-on
• Dimensions:
  • Height: 5.66 in
  • Width: 1.96 in
  • Depth: 4.05 in
• Weight: 3 lb (1.36 kg)
• Tightening Torque:
  • 34.52 lbf·in (AWG 14–AWG 10)
  • 49.56 lbf·in (AWG 8–AWG 2/0)

Material Compliance and Certifications

• cULus Certified: Confirms it meets rigorous North American safety requirements.
• Ambient Temperature Rating: Rated to operate reliably in temperatures up to 104 °F (40 °C).
• Green Premium Label: Reflects adherence to environmental compliance standards — offering transparency about material choices and supporting more sustainable, low‑CO₂ manufacturing practices.

Where It Works Best
