EDB24070 - 70 Amp Circuit Breaker

EDB24070 - 70 Amp Circuit Breaker

Get dependable circuit protection you can count on with the Schneider Electric EDB24070 miniature circuit breaker. Designed for homes, businesses, and light industrial setups, this 2-pole, 70-amp bolt-on breaker brings peace of mind — automatically cutting power when overloads or short circuits happen. Its compact E-frame design is ideal for NF panelboards, giving you a clean and efficient installation without eating up valuable panel space. Whether you’re wiring a new lighting setup or upgrading an existing panelboard, this breaker delivers reliable performance that keeps circuits safe and equipment protected.

Key Features and Benefits

• Thermal‑Magnetic Trip Unit: Automatically switches off the circuit in the event of an overload or short circuit, helping prevent damage to wiring and equipment.
• High Interrupt Rating (25 kA): Handles substantial fault currents without compromising safety, giving added protection to sensitive electrical systems.
• Bolt‑On Mounting: Ensures a secure, stable installation in NF panelboards; no loose fittings, just a firm and proper connection.
• Long Service Life: Built to last for many years, providing dependable protection over a long service horizon.
• Compact Footprint: E-frame construction allows for space-efficient installations — perfect when panel space is limited or you’re working within tight enclosures.

Technical Specifications

• Amperage: 70 A
• Poles: 2 (Double-pole)
• Voltage Rating: 480Y/277 VAC
• Interrupt Rating: 25 kA @ 120 VAC
• Hold Current: 630 A
• Trip Current: 1800 A
• Mounting Mode: Bolt‑on
• Dimensions:
  • Height: 5.66 in
  • Width: 1.96 in
  • Depth: 4.05 in
• Weight: 3 lb (1.36 kg)
• Operating Temperature: Up to 104 °F (40 °C)
• Certifications: cULus
• Compliance Rating: HACR (Heating, Air Conditioning & Refrigeration) compatible

Material Compliance and Certifications

• Environmental Standards: The EDB24070 is part of a certified premium product lineup that meets both environmental and safety standards. It is compliant with RoHS and REACH regulations, ensuring it is free of harmful heavy metals and other restricted substances. Designed without mercury, it aligns with modern environmental requirements and supports safer, greener installations — a smart choice for any eco-conscious project.

Where It Works Best

• This 70A bolt‑on breaker is ideal for use in NF panelboards, whether you’re handling lighting circuits, branch circuits, or small motor loads in residential, commercial, or light industrial settings. Its space-saving size and high interrupt capacity make it particularly well-suited for lighting panelboards or retrofit upgrades where reliable protection and efficient use of panel space are priorities.
