EDB24060 - 60A Circuit Breaker

EDB24060 60A Circuit Breaker

Enhance your electrical systems with the Schneider Electric EDB24060 Circuit Breaker, designed for superior performance and reliability. This miniature bolt-on circuit breaker is an essential component for any lighting panelboard setup, offering robust features and advanced technology to ensure optimal protection for your electrical systems. With a 60A rating and 2 poles, it operates efficiently at 480Y/277 VAC and provides a maximum interrupting capacity of 25 kA. Designed to protect low-voltage electronics, this circuit breaker mounts directly onto NF panelboards, providing a secure and dependable solution for managing electrical overloads and short circuits.

Key Features and Benefits:

• Robust Protection: Thermal-magnetic trip unit ensures reliable protection against overloads and short circuits.
• Durability: Built to last with a lifespan of up to 20 years, offering long-term reliability.
• HACR Rated: Suitable for Heating, Air Conditioning, and Refrigeration applications, ensuring versatile use.
• Bolt-On Mounting: Secure and straightforward installation onto NF panelboards for dependable connectivity.

Technical Specifications:

• Range: 125 A Frame EDB-EGB-EJB
• Device Type: Miniature circuit-breaker
• Trip Unit Rating: 2300 A
• Line Rated Current: 100 A
• Voltage: 480Y/277 V AC
• Breaking Capacity: 18 kA at 277 V AC, 25 kA at 120 V AC, 18 kA at 480Y/277 V AC, 25 kA at 120/240 V AC
• Poles: 2
• Dimensions: Height: 5.66 in, Width: 3.92 in, Depth: 4.05 in
• Weight: 4 lb (1.81 kg)

Material Compliance and Certifications:

• Certifications: cULus certified, ensuring compliance with safety standards.
• Environmental Performance: Green Premium‰ã¢ label guarantees adherence to environmental regulations, transparency on environmental impacts, and commitment to sustainability.
• RoHS Compliance: Meets EU RoHS Directive, ensuring the product is free from hazardous substances.
• REACh Regulation: Complies with REACh standards, providing safety and environmental assurance.

Suitability:

• The Schneider Electric EDB24060 Circuit Breaker is ideally suited for use in lighting panelboards, particularly within commercial and industrial environments where reliability and safety are paramount. Its HACR rating makes it an excellent choice for HVAC applications, ensuring versatile functionality across various systems. This circuit breaker is designed for those who need robust protection for low-voltage electronics, making it an essential component for maintaining the integrity of your electrical infrastructure.
