EDB24050 - 50 Amp Circuit Breaker

EDB24050 - 50 Amp Circuit Breaker

Keep your electrical system safe and dependable with the EDB24050 50A Miniature Circuit Breaker — a high‑quality circuit protection solution built by Schneider Electric. Designed specifically for use with Square D NF Panelboards, this 2‑pole breaker delivers reliable performance whether you’re upgrading an existing installation or wiring a new one. Its 50 amp rating makes it a strong choice for residential, commercial, or light‑industrial circuits that require consistent protection against overloads and short circuits.

Key Features and Benefits

• High Interrupt Capacity: With the ability to interrupt up to 25 kA at 120 VAC, the EDB24050 offers dependable protection against serious short circuits, giving you peace of mind that your system is safe under fault conditions.
• Thermal-Magnetic Trip Unit: The built-in thermal-magnetic mechanism provides accurate and responsive trip action — safeguarding your wiring and equipment from both prolonged overloads and sudden surges.
• Bolt-On Mounting: The bolt-on configuration makes installation straightforward and secure, ensuring a stable connection that won’t loosen over time.
• Long Service Life: Engineered for durability, this breaker can deliver long-term use — typically lasting up to two decades — ensuring your electrical system remains protected for years.

Technical Specifications

• Current Rating: 50 A
• Number of Poles: 2 (Double Pole)
• Maximum Operating Voltage: 480Y/277 VAC
• Interrupt Rating: 25 kA at 120 VAC
• Mounting Mode: Bolt‑on
• Dimensions: Height – 5.66 in (143.8 mm), Width – 1.96 in (49.8 mm), Depth – 4.05 in (102.9 mm)
• Weight: Approx. 3 lb (1.36 kg)

Material Compliance and Certifications

• UL Listed: Complies with rigorous safety and performance standards to meet industry requirements for circuit breakers.
• HACR and HID Rated: Suitable for use in heating, air conditioning, and refrigeration (HACR) systems, as well as high‑intensity discharge (HID) lighting applications.
• Green Premium Label: Manufactured with attention to environmental impact and sustainability, this breaker adheres to current standards for eco‑friendly electrical components.

Where It Works Best

• The EDB24050 is an excellent fit for a wide range of settings — from modern homes to commercial properties and light industrial installations. Use it in Square D NF panelboards to protect HVAC circuits, lighting systems, kitchen appliances, or other medium‑ to heavy‑duty loads. It’s particularly well-suited for retrofit projects and new builds alike, offering consistent, reliable protection for wiring systems that demand dependable circuit interruption without fuss.
