EDB24045 - 45Amp Circuit Breaker

EDB24045 - 45Amp Circuit Breaker

Introducing the EDB24045 Mini Circuit Breaker, a premium component designed to deliver exceptional performance and reliability for your electrical systems. This state-of-the-art E-Frame breaker from Schneider Electric is engineered for use in Square D NF Panelboards, ensuring superior overload and short circuit protection. Rated at 45A with a 2-pole configuration, this breaker operates at 480Y/277 VAC with a maximum interrupt rating of 25 kA, making it ideal for both residential and commercial lighting applications. Its thermal-magnetic trip unit provides precise tripping, while the built-in trip indicator offers clear status updates. The bolt-on design ensures secure and straightforward installation, providing robust protection for your electrical systems.

Key Features and Benefits:

• Robust Protection: Provides superior overload and short circuit protection, ensuring safety and reliability.
• High Performance: Operates at 480Y/277 VAC with a 25 kA max interrupt rating, suitable for demanding electrical environments.
• Thermal-Magnetic Trip Unit: Delivers precise and reliable tripping, minimizing downtime and protecting your equipment.
• Bolt-On Design: Ensures secure installation and easy integration into Square D NF Panelboards.

Technical Specifications:

• Range: 125 A Frame EDB-EGB-EJB
• Product Type: Miniature Circuit Breaker
• Device Short Name: EDB
• Trip Unit Rating: 1800 A
• Line Rated Current: 45 A
• Maximum Operating Voltage: 480Y/277 V AC
• Breaking Capacity:åÊ18 kA at 277 V AC,åÊ25 kA at 240 V AC,åÊ18 kA at 480Y/277 V AC,åÊ25 kA at 120 V AC,åÊ25 kA at 120/240 V AC
• Electrical Connection: Lugs aluminium
• Mounting Mode: Bolt-on
• Number of Poles: 2
• Dimensions: Height: 5.66 in (143.76 mm),åÊWidth: 1.96 in (49.78 mm),åÊDepth: 4.05 in (102.87 mm)
• Net Weight: 3 lb (1.36 kg)
• Operating Temperature: 104 å¡F (40 å¡C)

Material Compliance and Certifications:

• Certifications: cULus Listed
• Environmental Performance: Green Premium‰ã¢ label, ensuring compliance with the latest regulations and a commitment to sustainability. The product is mercury-free and complies with RoHS, REACh, and other global standards.
• Sustainability: Designed with eco-friendly materials and processes, reducing environmental impact and promoting circular economy practices.

Suitability:

• The EDB24045 Mini Circuit Breaker is specifically designed for use in Square D NF Panelboards, making it ideal for both residential and commercial lighting applications. Its robust design and high interrupt capacity ensure reliable protection for your electrical systems, making it a trusted choice for professionals and DIY enthusiasts alike.
