The Square D EDB24035 is a dependable 35 Amp, 2-pole E-Frame circuit breaker engineered to provide reliable branch circuit protection in Square D NF panelboards. Designed for commercial and industrial electrical systems, this bolt-on breaker combines proven thermal-magnetic trip technology with a secure mounting design to help protect electrical equipment from overloads and short circuits. Whether you're replacing an existing EDB-series breaker during routine maintenance or installing a new electrical distribution system, the EDB24035 delivers the performance, compatibility, and durability professionals expect. Operating on 480Y/277V AC systems, it features a built-in trip indicator that quickly identifies when the breaker has opened, making troubleshooting faster and reducing system downtime.

Key Features and Benefits

• 35 Amp, 2-pole E-Frame circuit breaker for Square D NF panelboards
• Secure bolt-on mounting provides a stable mechanical and electrical connection
• Thermal-magnetic trip unit protects against overloads and short-circuit faults
• Rated for 480Y/277V AC commercial and industrial electrical systems
• Interrupting capacity up to 25 kAIC for dependable fault protection
• Built-in trip indicator simplifies maintenance and troubleshooting
• HID rated for high-intensity discharge lighting applications
• HACR rated for heating, air conditioning, and refrigeration equipment
• Accepts copper and aluminum conductors for installation flexibility
• Ideal for replacement projects, preventive maintenance, and electrical system upgrades


Technical Specifications

• Catalog Number: EDB24035

• Manufacturer: Square D by Schneider Electric

• Product Type: Miniature Circuit Breaker

• Series: E-Frame (EDB)

• Frame Size: 125 Amp Frame

• Rated Current: 35 Amps

• Maximum Operating Voltage: 480Y/277V AC

• Poles: 2

• Number of Spaces Required: 2

• Mounting Style: Bolt-On

• Compatible Panelboards: Square D NF Panelboards

• Trip Unit Technology: Thermal-Magnetic

• Trip Unit Rating: 1800 Amps

• Holding Current: 630 Amps

• Protection Type: Overload and Short Circuit

• Interrupting Capacity:
  • 25 kAIC @ 120V AC
  • 25 kAIC @ 120/240V AC
  • 25 kAIC @ 240V AC
  • 18 kAIC @ 277V AC
  • 18 kAIC @ 480Y/277V AC
• Electrical Connections: Aluminum Lugs

• Accepted Wire Sizes:
  • Copper: AWG 14–2/0
  • Aluminum: AWG 12–2/0
• Terminal Torque:
  • 34.5 lb-in (3.9 N·m) for AWG 14–10
  • 49.6 lb-in (5.6 N·m) for AWG 8–2/0
• Calibration Temperature: 40°C (104°F)

• Dimensions:
  • Height: 5.66 in. (143.76 mm)
  • Width: 1.96 in. (49.78 mm)
  • Depth: 4.05 in. (102.87 mm)
• Weight: 3 lb (1.4 kg)


Material Compliance and Certifications

The Square D EDB24035 is cULus Listed, demonstrating compliance with recognized North American safety and performance standards. It is also HID rated for high-intensity discharge lighting applications and HACR rated for heating, air conditioning, and refrigeration equipment. In addition, this breaker is TAA compliant and calibrated for reliable operation in ambient temperatures up to 40°C (104°F). Installation should always be completed by qualified electrical personnel in accordance with applicable national and local electrical codes.

•  cULus Listed
•  HID rated
•  HACR rated
• TAA compliant.


Where It Works Best

• Square D NF lighting panelboards
• Commercial and industrial electrical distribution systems
• 480Y/277V AC branch circuit protection
• Office buildings, schools, hospitals, retail centers, and municipal facilities
• Manufacturing plants and industrial facilities
• High-intensity discharge (HID) lighting systems
• Heating, air conditioning, and refrigeration (HACR) equipment
• Commercial lighting and equipment branch circuits
• Replacement of existing EDB-series bolt-on circuit breakers
• Preventive maintenance, panel upgrades, and electrical modernization projects
