EDB24030 - 30A Circuit Breaker

EDB24030 30A Circuit Breaker

The EDB24030 Miniature Circuit Breaker, part of the Schneider Electric E-Frame series, offers robust protection for your low-voltage electronics. This 30A, 2-pole circuit breaker is designed to be mounted on NF panelboards, ensuring reliable performance and safety in lighting applications.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Provides superior protection by combining both thermal and magnetic tripping mechanisms to handle overloads and short circuits effectively.
• High Interrupting Capacity: Rated up to 25 kA at 240 VAC, ensuring reliable performance in demanding environments.
• Durability: Designed to last up to 20 years, providing long-term reliability and safety.
• Ease of Installation: Bolt-on mounting simplifies installation, making it ideal for use in Square D NF Panelboards.

Technical Specifications:

• Rated Current: 30 A
• Poles: 2
• Voltage Rating: 480Y/277 VAC
• Interrupt Rating: 25 kA at 240 VAC
• Trip Unit Rating: 875 A
• Mounting Mode: Bolt-on
• Dimensions: 5.66 in (height) x 1.96 in (width) x 4.05 in (depth)
• Weight: 3 lb (1.36 kg)

Material Compliance and Certifications:

• UL Listed: Certified for safety and performance, ensuring compliance with industry standards.
• HID and HACR Rated: Suitable for high-intensity discharge lighting and heating, air conditioning, and refrigeration applications.
• Environmental Compliance: Green Premium‰ã¢ label, RoHS, and REACh declarations ensure the product meets stringent environmental and safety regulations.

Suitability:

• The EDB24030 is perfect for commercial and industrial applications requiring reliable circuit protection for lighting panelboards. Its high interrupting capacity and durable design make it suitable for environments where safety and longevity are paramount. Additionally, its compatibility with numerous accessories provides flexibility in various installation scenarios.
