EDB14040 - 40A Circuit Breaker

EDB14040 40A Circuit Breaker

The Schneider Electric EDB14040 circuit breaker is a high-performance, reliable solution designed for low-voltage electronic protection. This miniature bolt-on mount circuit breaker is part of the E-frame series, ensuring optimal safety and efficiency for lighting panelboards. With a 40A current rating, a single pole, and an operating voltage of 277 VAC, it is an ideal choice for various commercial and industrial applications.

Key Features and Benefits:

• High Interrupting Capacity: Offers a maximum interrupt rating of 25 kA at 120 VAC, ensuring robust protection against short circuits.
• Thermal-Magnetic Trip Unit: Equipped with a thermal-magnetic trip unit for accurate and reliable protection against overloads and short circuits.
• Durability: Designed to last up to 20 years, providing long-term reliability and peace of mind.
• HID and HACR Rated: Suitable for high-intensity discharge lighting and heating, air conditioning, and refrigeration applications.
• Bolt-On Mounting: Easy installation with bolt-on mounting, directly compatible with Square D NF panelboards.

Technical Specifications:

• Device Short Name: EDB
• Current Rating: 40 A
• Number of Poles: 1
• Maximum Operating Voltage: 277 V AC
• Breaking Capacity: 25 kA at 120 V AC, 18 kA at 240 V AC and 277 V AC, 18 kA at 120/240 V AC
• Trip Unit Rating: 1800 A
• Mounting Mode: Bolt-on
• Electrical Connection: Lugs aluminum
• Product Certifications: UL Listed, cULus, IEC
• Dimensions: Height - 5.66 in (143.76 mm), Width - 0.98 in (24.89 mm), Depth - 4.05 in (102.87 mm)
• Net Weight: 2 lb (0.91 kg)

Material Compliance and Certifications:

• Green Premium‰ã¢ Label: Schneider Electric's commitment to delivering environmentally friendly products with best-in-class performance. This product complies with the latest regulations and offers transparency on environmental impacts.
• RoHS Compliance: Pro-active compliance with EU RoHS Directive, ensuring the product is free from hazardous substances.
• REACh Declaration: Fully compliant with the REACh Regulation, ensuring safe use of chemicals.
• China RoHS Declaration: Adheres to the China RoHS regulations, ensuring it meets strict environmental standards.

Suitability:

• The EDB14040 circuit breaker is engineered for lighting panelboards in commercial and industrial settings. It is perfect for applications requiring dependable protection against overloads and short circuits. Its HID and HACR ratings make it versatile for use in lighting, heating, air conditioning, and refrigeration systems. The easy-to-install bolt-on mounting ensures quick integration with Square D NF panelboards, providing a reliable and durable solution for various electrical protection needs.
