EDB14015 - 15 -A Circuit Breaker

EDB14015 15A Circuit Breaker

Introducing the EDB14015 Mini Circuit Breaker, a high-performance, reliable solution from Schneider Electric designed to ensure maximum protection and operational efficiency in your electrical systems. This E-Frame circuit breaker, with a line rated current of 15A and a maximum operating voltage of 277 VAC, is engineered to deliver robust protection against short circuits and overloads, ensuring the safety and reliability of your electrical installations.

Key Features and Benefits

• Reliable Performance: The EDB14015 is designed to handle a maximum breaking capacity of 25 kA at 120 VAC, providing exceptional protection for your electrical circuits.
• Compact Design: Its miniature size and bolt-on mounting mode make it ideal for space-constrained applications without compromising on performance.
• Thermal-Magnetic Trip Unit: Ensures precise tripping characteristics for effective protection against overloads and short circuits.
• Versatile Application: Suitable for various applications, including HACR and HID rated circuits, enhancing its versatility across different electrical systems.
• User-Friendly: Features a trip indicator for easy local signaling and a tightening torque specification for secure connections.

Technical Specifications

• Product Range: 125 A Frame EDB-EGB-EJB
• Device Short Name: EDB
• Module Type: E-Frame
• Trip Unit Rating: 875 A
• Line Rated Current: 15 A
• Maximum Operating Voltage: 277 V AC
• Breaking Capacity: 18 kA at 277 V AC,åÊ18 kA at 240 V AC,åÊ25 kA at 120 V AC,åÊ18 kA at 120/240 V AC
• Electrical Connection: Lugs aluminum, AWG 12 to AWG 6 for aluminum, AWG 14 to AWG 6 for copper
• Mounting Mode: Bolt-on
• Dimensions: Height: 5.66 in (143.76 mm), Width: 0.98 in (24.89 mm), Depth: 4.05 in (102.87 mm)
• Weight: 2 lb (0.91 kg)

Material Compliance and Certifications

• Certifications: cULus, IEC
• Environmental Compliance: Green Premium‰ã¢ label, RoHS compliant, REACh Declaration
• Operating Temperature: Suitable for use up to 104 å¡F (40 å¡C)

Suitability

• The EDB14015 Mini Circuit Breaker is perfectly suited for integration into NF panelboards and other electrical systems requiring compact, reliable protection. Its robust design and advanced features make it an ideal choice for both residential and commercial applications, ensuring safety and compliance with stringent industry standards.
