ED41B050 - 50Amp Circuit Breaker

ED41B050 - 50Amp Circuit Breaker

Introducing the Siemens ED41B050 circuit breaker, a robust and reliable solution designed for modern electrical systems. This low voltage, molded case circuit breaker features a thermal-magnetic trip unit, offering superior protection and efficiency. With its standard 40å¡C breaker ED frame and standard breaking capacity, it meets UL 489 and IEC 60947-2 standards, ensuring high performance and safety in diverse applications.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Provides accurate and reliable protection by combining thermal and magnetic trip functionalities, ideal for both overload and short-circuit conditions.
• Standard Breaking Capacity: Ensures dependable performance with a breaking capacity of 22KAIC at 277V, suitable for various commercial and industrial applications.
• Load Lugs Only (LD1E060): Simplifies installation and connection with load lugs that support a wire range of 10 - 4AWG (CU/AL), enhancing flexibility and ease of use.

Technical Specifications:

• Frame Type: ED Frame
• Trip Unit: Thermal-Magnetic
• Rated Current: 50A
• Poles: 1-Pole
• Breaking Capacity: 22KAIC at 277V
• Wire Range: 10 - 4AWG (CU/AL)
• Dimensions (W x H x D): 1 x 6.35 x 3.92 inches
• Weight: 1.199 lbs
• Standards: UL 489, IEC 60947-2

Material Compliance and Certifications:

• Compliance: The Siemens ED41B050 circuit breaker is manufactured in compliance with the latest industry standards. It adheres to the UL 489 and IEC 60947-2 standards, ensuring top-notch safety and performance. Additionally, it complies with the RoHS directive since March 31, 2009, guaranteeing it is free from hazardous substances, making it an environmentally responsible choice.

Suitability:

• This circuit breaker is suitable for a wide range of applications, including commercial, industrial, and residential settings. Its robust construction and reliable performance make it an excellent choice for protecting electrical systems from overloads and short circuits, ensuring the safety and longevity of your electrical infrastructure.

Upgrade your electrical systems with the Siemens ED41B050 circuit breaker, a reliable and efficient solution designed to meet your modern electrical needs.
