Keeping your electrical system running safely and efficiently starts with choosing the right replacement breaker. The Eaton ED2175 Series C Complete Molded Case Circuit Breaker is engineered as a form, fit, and functional replacement for compatible Eaton Series C ED-frame applications, making it a dependable solution for maintenance, repairs, and equipment servicing. With a 175-amp rating, two-pole configuration, and a 65 kAIC interrupt rating at 240 VAC, this breaker provides dependable protection against overloads and short circuits while maintaining compatibility with the original electrical system design.

Built on Eaton's F-frame platform, this complete molded case circuit breaker is built to last and is commonly used in commercial, industrial, and institutional electrical distribution systems where maintaining original specifications and dependable circuit protection is essential.

Key Features and Benefits

• Designed as a form, fit, and functional replacement for compatible Eaton Series C ED-frame circuit breakers
• 175 amp continuous current rating
• Two-pole molded case circuit breaker
• Rated for 240 VAC and 125 VDC electrical systems
• 65 kAIC interrupt rating at 240 VAC
• T186 thermal-magnetic trip unit for overload and short-circuit protection
• Complete breaker with F-frame construction
• Load terminal configuration for compatible installations
• Suitable for 50/60 Hz applications
• Built to last for dependable service in compatible electrical distribution systems

Technical Specifications

• Manufacturer: Eaton

• Series: Series C

• Catalog Number: ED2175

• Product Type: Complete Molded Case Circuit Breaker

• Circuit Breaker Type: ED

• Frame: F Frame

• Amperage Rating: 175 A

• Poles: 2

• Voltage Rating: 240 VAC, 125 VDC

• Frequency: 50/60 Hz

• Interrupt Rating: 65 kAIC at 240 VAC

• Trip Type: T186

• Terminal Type: Load

• Dimensions: 3.38 in (L) × 2.75 in (W) × 6.00 in (H)

• Weight: 2.9 lb


Material Compliance and Certifications

• UL Listed
• Manufactured to meet applicable UL safety requirements
• Covered by Eaton's standard warranty in accordance with the applicable Eaton Selling Policy


Where It Works Best

The Eaton ED2175 is commonly installed in compatible commercial, industrial, and institutional electrical distribution systems that require a 175 amp, two-pole molded case circuit breaker. It is suitable for use in compatible panelboards, switchboards, control panels, and other power distribution equipment designed for Eaton Series C ED-frame breakers. Whether used for routine maintenance or emergency replacement, the ED2175 helps maintain system compatibility by preserving the original form, fit, and function while providing dependable overcurrent protection in compatible applications.
