EB1030L - 30Amp Circuit Breaker

EB1030L - 30Amp Circuit Breaker

The EB1030L is a 30 Amp, single-pole thermal magnetic circuit breaker commonly found in electrical panels and distribution equipment manufactured before 1989. If you're servicing an older electrical system, you know that replacing a breaker is often about maintaining compatibility rather than changing the design. The EB1030L was built for exactly that purpose, helping preserve the original panel configuration while providing the electrical ratings required for compatible EB installations.

This breaker features a thermal-magnetic trip mechanism, a long-established design used throughout electrical distribution systems. The thermal element responds to sustained overload conditions, while the magnetic element reacts quickly when a short-circuit fault occurs. Together, these functions help protect branch circuits, conductors, and connected equipment during normal operation.

With a 30 Amp rating, 120VAC capacity, and 10kA interrupting rating, the EB1030L is suitable for a wide range of branch circuit applications found in older electrical systems. This version includes both line and load terminals, which can help simplify installation and replacement work when servicing compatible panelboards and load centers.

Key Features and Benefits

• 30 Amp single-pole circuit breaker
• Designed for use in compatible EB panelboards and load centers
• Thermal-magnetic trip mechanism for overload and short-circuit protection
• Rated for 120VAC applications
• 10kA interrupting capacity
• Includes both line-side and load-side terminals
• Non-interchangeable trip unit design
• 40°C rated construction
• Suitable for maintenance and replacement applications
• Helps maintain original panel configuration and breaker layout
• Designed for panels manufactured before 1989
• Compact footprint for legacy electrical systems
• Built for long-term use in existing installations

Technical Specifications

• Part Number: EB1030L

• Product Type: Thermal Magnetic Circuit Breaker

• Series/Type: EB

• Amperage Rating: 30 Amps

• Voltage Rating: 120VAC

• Poles: 1

• Interrupting Rating: 10kAIC @ 120VAC

• Trip Unit: Non-Interchangeable

• Operating Temperature Rating: 40°C

• Terminals Included: Line and Load Terminals

• Width: 1.38 in

• Height: 6.0 in

• Depth: 3.38 in

• Dimensions: 1.38"W x 6.0"H x 3.38"D

• Approximate Shipping Weight: 3.0 lbs


Material Compliance and Certifications

The EB1030L is intended for use in compatible electrical distribution equipment designed to accept EB-series circuit breakers. It is commonly used for replacement, maintenance, and repair work in existing installations. Installation should be performed by qualified electrical personnel in accordance with applicable electrical codes, equipment manufacturer requirements, and site-specific safety practices.

Where It Works Best

• Electrical panels manufactured before 1989
• Legacy panelboard and load center installations
• 120VAC branch circuits
• Commercial electrical distribution systems
• Industrial electrical distribution systems
• Institutional and government facilities
• Building maintenance and repair projects
• Panel restoration and refurbishment work
• Replacement of existing EB-series breakers
• Facilities maintaining original electrical infrastructure
• Applications requiring single-pole circuit protection
