EB1030 - 30Amp Circuit Breaker

EB1030 - 30Amp Circuit Breaker

The EB1030 is a 30 Amp, single-pole thermal magnetic circuit breaker commonly used in electrical panels and distribution equipment manufactured before 1989. If you're maintaining an older electrical system, finding the correct replacement breaker is often about preserving compatibility rather than making changes to equipment that continues to do its job. The EB1030 was designed for exactly that purpose, helping maintain the original panel configuration while providing the electrical ratings required for compatible EB installations.

Many commercial buildings, schools, industrial facilities, and government properties still rely on electrical panels that have been operating reliably for decades. When a breaker needs replacement, matching the original specifications can help simplify maintenance and keep the system consistent with its original design. The EB1030 is frequently used for panel repairs, preventative maintenance, and restoration projects where maintaining the existing protection scheme is a priority.

With a 30 Amp rating, 120VAC capacity, and 10kA interrupting rating, the EB1030 is well suited for many branch circuit applications found in legacy electrical systems. The included load terminals can help make replacement work more efficient when servicing compatible panelboards and load centers.

Key Features and Benefits

• 30 Amp single-pole circuit breaker
• Designed for use in compatible EB panelboards and load centers
• Thermal-magnetic trip mechanism for overload and short-circuit protection
• Rated for 120VAC applications
• 10kA interrupting capacity
• Includes load terminals
• Non-interchangeable trip unit design
• 40°C rated construction
• Suitable for maintenance and replacement applications
• Helps maintain original panel configuration and breaker layout
• Designed for panels manufactured before 1989
• Compact footprint for legacy electrical systems
• Built for long-term use in existing installations

Technical Specifications

• Part Number: EB1030

• Product Type: Thermal Magnetic Circuit Breaker

• Series/Type: EB

• Amperage Rating: 30 Amps

• Voltage Rating: 120VAC

• Poles: 1

• Interrupting Rating: 10kAIC @ 120VAC

• Trip Unit: Non-Interchangeable

• Operating Temperature Rating: 40°C

• Terminals Included: Load Terminals

• Width: 1.38 in

• Height: 6.0 in

• Depth: 3.38 in

• Dimensions: 1.38"W x 6.0"H x 3.38"D

• Approximate Shipping Weight: 3.0 lbs


Material Compliance and Certifications

The EB1030 is intended for use in compatible electrical distribution equipment designed to accept EB-series circuit breakers. It is commonly used for replacement, maintenance, and repair work in existing installations. Installation should be performed by qualified electrical personnel and in accordance with applicable electrical codes, equipment manufacturer requirements, and site-specific safety practices.

Where It Works Best

• Electrical panels manufactured before 1989
• Legacy panelboard and load center installations
• 120VAC branch circuits
• Commercial electrical distribution systems
• Industrial electrical distribution systems
• Institutional and government facilities
• Building maintenance and repair projects
• Panel restoration and refurbishment work
• Replacement of existing EB-series breakers
• Facilities maintaining original electrical infrastructure
• Applications requiring single-pole circuit protection
