EB1020 - 20Amp Circuit Breaker

EB1020 - 20Amp Circuit Breaker

The EB1020 is a 20 Amp, single-pole thermal magnetic circuit breaker commonly used in electrical panels and distribution equipment manufactured before 1989. If you're working on an older electrical system, you already know that finding the correct replacement breaker is often about maintaining compatibility rather than changing the design. The EB1020 was built for that purpose, helping keep existing equipment operating with the same form, fit, and electrical characteristics the original installation was designed around.

Many commercial properties, schools, manufacturing facilities, and public buildings continue to rely on electrical panels that have been in service for decades. When one of those systems requires maintenance, matching the original breaker specifications can help simplify repairs and preserve the panel's existing layout. The EB1020 is frequently used in these situations, making it a practical choice for electricians and maintenance teams responsible for supporting legacy electrical infrastructure.

With a 20 Amp rating, 120VAC capacity, and 10kA interrupting rating, the EB1020 is suitable for a wide range of branch circuit applications found in older electrical systems. The included load terminals can help streamline replacement work, particularly when servicing compatible EB panelboards and load centers.

Key Features and Benefits

• 20 Amp single-pole circuit breaker
• Designed for use in compatible EB panelboards and load centers
• Thermal-magnetic trip mechanism for overload and short-circuit protection
• Rated for 120VAC applications
• 10kA interrupting capacity
• Includes load terminals
• Non-interchangeable trip unit design
• 40°C rated construction
• Suitable for maintenance and replacement applications
• Helps maintain original panel configuration and breaker layout
• Designed for panels manufactured before 1989
• Compact footprint for legacy electrical systems
• Built for long-term use in existing installations

Technical Specifications

• Part Number: EB1020

• Product Type: Thermal Magnetic Circuit Breaker

• Series/Type: EB

• Amperage Rating: 20 Amps

• Voltage Rating: 120VAC

• Poles: 1

• Interrupting Rating: 10kAIC @ 120VAC

• Trip Unit: Non-Interchangeable

• Operating Temperature Rating: 40°C

• Terminals Included: Load Terminals

• Width: 1.38 in

• Height: 6.0 in

• Depth: 3.38 in

• Dimensions: 1.38"W x 6.0"H x 3.38"D

• Approximate Shipping Weight: 3.0 lbs


Material Compliance and Certifications

The EB1020 is intended for use in compatible electrical distribution equipment designed to accept EB-series circuit breakers. It is commonly used for replacement, maintenance, and repair work in existing installations. Installation should be performed by qualified electrical personnel and in accordance with applicable electrical codes, equipment manufacturer requirements, and site-specific safety practices.

Where It Works Best

• Electrical panels manufactured before 1989
• Legacy panelboard and load center installations
• 120VAC branch circuits
• Commercial electrical distribution systems
• Industrial electrical distribution systems
• Institutional and government facilities
• Building maintenance and repair projects
• Panel restoration and refurbishment work
• Replacement of existing EB-series breakers
• Facilities maintaining original electrical infrastructure
• Applications requiring single-pole circuit protection
