EB1015L - 15Amp Circuit Breaker

EB1015L - 15Amp Circuit Breaker

The EB1015L is a 15 Amp, single-pole thermal magnetic circuit breaker commonly used in electrical panels and distribution equipment manufactured before 1989. If you're maintaining an older electrical system, finding the right replacement breaker is often about preserving what's already working rather than redesigning the panel. The EB1015L was designed for those situations, providing the ratings and configuration needed to match compatible EB installations.

Many commercial buildings, schools, industrial facilities, and institutional properties continue to operate electrical equipment that has been in service for decades. When a breaker needs replacement, using a compatible unit helps maintain the original panel layout and keeps the electrical system consistent with its intended design. The EB1015L is frequently used for maintenance and repair projects where matching the existing breaker style is an important part of the job.

With a 15 Amp rating, 120VAC capacity, and 10kA interrupting rating, the EB1015L is suitable for a wide range of branch circuit applications found in legacy electrical systems. This version includes both line and load terminals, which can make replacement work more straightforward when servicing existing panels.

Key Features and Benefits

• 15 Amp single-pole circuit breaker
• Designed for use in compatible EB panelboards and load centers
• Thermal-magnetic trip mechanism for overload and short-circuit protection
• Rated for 120VAC applications
• 10kA interrupting capacity
• Includes both line-side and load-side terminals
• Non-interchangeable trip unit design
• 40°C rated construction
• Suitable for maintenance and replacement applications
• Helps maintain original panel configuration and breaker layout
• Designed for panels manufactured before 1989
• Built for long-term use in existing electrical systems

Technical Specifications

• Part Number: EB1015L

• Product Type: Thermal Magnetic Circuit Breaker

• Series/Type: EB

• Amperage Rating: 15 Amps

• Voltage Rating: 120VAC

• Poles: 1

• Interrupting Rating: 10kAIC @ 120VAC

• Trip Unit: Non-Interchangeable

• Operating Temperature Rating: 40°C

• Terminals Included: Line and Load Terminals

• Width: 1.38 in

• Height: 6.0 in

• Depth: 3.38 in

• Dimensions: 1.38"W x 6.0"H x 3.38"D

• Approximate Shipping Weight: 3.0 lbs


Material Compliance and Certifications

The EB1015L is intended for use in compatible electrical distribution equipment designed to accept EB-series circuit breakers. It is commonly used for replacement, maintenance, and repair work in existing installations. Installation should be performed by qualified electrical personnel in accordance with applicable electrical codes, equipment manufacturer requirements, and site-specific safety practices.

Where It Works Best

• Electrical panels manufactured before 1989
• Legacy panelboard and load center installations
• 120VAC branch circuits
• Commercial electrical distribution systems
• Industrial electrical distribution systems
• Institutional and government facilities
• Building maintenance and repair projects
• Panel restoration and refurbishment work
• Replacement of existing EB-series breakers
• Facilities maintaining original electrical infrastructure
• Applications requiring single-pole circuit protection
