EB1015 - 15Amp Circuit Breaker

EB1015 - 15Amp Circuit Breaker

The EB1015 is a 15 Amp, single-pole thermal magnetic circuit breaker commonly used in electrical panels and distribution equipment manufactured before 1989. When you're maintaining older electrical systems, finding the correct replacement breaker is often less about changing the system and more about preserving the original design. That's where the EB1015 fits in—providing the form, fit, and electrical ratings needed to keep compatible equipment operating as intended.

Many older commercial buildings, industrial facilities, and institutional properties continue to rely on electrical panels that have been in service for decades. When a breaker requires replacement, matching the original breaker type helps maintain consistency throughout the panel and avoids unnecessary modifications.

With a 15 Amp rating, 120VAC capacity, and 10kA interrupting rating, the EB1015 is suitable for many standard branch circuit applications found in legacy electrical systems. The included load terminals can help simplify replacement work, especially when servicing existing panels where maintaining the original configuration is important.

Key Features and Benefits

• 15 Amp single-pole circuit breaker
• Designed for use in compatible EB panelboards and load centers
• Thermal-magnetic trip mechanism for overload and short-circuit protection
• Rated for 120VAC systems
• 10kA interrupting capacity
• Includes load terminals
• Non-interchangeable trip unit design
• 40°C rated construction
• Suitable for maintenance and replacement applications
• Helps maintain original panel configuration and breaker layout
• Compact footprint for legacy electrical systems
• Built for long-term use in existing installations

Technical Specifications

• Part Number: EB1015

• Product Type: Thermal Magnetic Circuit Breaker

• Series/Type: EB

• Amperage Rating: 15 Amps

• Voltage Rating: 120VAC

• Poles: 1

• Interrupting Rating: 10kAIC @ 120VAC

• Trip Unit: Non-Interchangeable

• Operating Temperature Rating: 40°C

• Terminals Included: Load Terminals

• Width: 1.38 in

• Height: 6.0 in

• Depth: 3.38 in

• Dimensions: 1.38"W x 6.0"H x 3.38"D

• Approximate Shipping Weight: 3.0 lbs


Material Compliance and Certifications

The EB1015 is intended for use in compatible electrical distribution equipment and panelboards designed to accept EB-series circuit breakers. It is commonly used for replacement, maintenance, and repair work in existing installations. Installation should be performed by qualified electrical personnel in accordance with applicable electrical codes, equipment manufacturer requirements, and site-specific safety procedures.

Where It Works Best

• Electrical panels manufactured before 1989
• Legacy panelboard and load center installations
• 120VAC branch circuits
• Commercial electrical distribution systems
• Industrial electrical distribution systems
• Building maintenance and repair projects
• Panel restoration and modernization projects
• Replacement of existing EB-series breakers
• Facilities maintaining original electrical equipment
• Applications requiring single-pole circuit protection
