E63A003 - 3Amp Motor Circuit Protector

E63A003 - 3 Amp Motor Circuit Protector

The E63A003 motor circuit interrupter is designed for use in electrical distribution systems that require dependable short-circuit protection for motor circuits. Built on the E6-A ETI frame, this 3-pole, 3-amp unit rated for up to 600VAC is commonly used in industrial control panels, motor control centers, and equipment where precise instantaneous protection is required. The interrupter features adjustable instantaneous trip settings that allow technicians to match protection levels to specific motor starting characteristics and operating conditions. With both line-side and load-side terminals included, installation and replacement in compatible legacy systems is straightforward. Products in this class were built to last and are often selected when maintaining or servicing existing electrical infrastructure where the original frame type and electrical ratings must be preserved.

Key Features and Benefits

• Motor Circuit Protection: Designed specifically as a motor circuit interrupter (MCI) for short-circuit protection in motor applications.
• 3-Pole Configuration: Supports three-phase electrical systems commonly used in industrial environments.
• Adjustable Instantaneous Trip Settings: Multiple settings allow technicians to align protection levels with motor starting currents and operational requirements.
• 600VAC Rating: Suitable for higher-voltage industrial power distribution systems.
• Included Line and Load Terminals: Helps simplify installation or replacement in compatible equipment.
• Form, Fit, and Functional Replacement: Matches the E6-A ETI frame type, supporting maintenance and repair of existing systems.
• Durable Construction: Equipment of this type was manufactured for long service life in demanding electrical environments.

Technical Specifications

• Part Number: E63A003
• Product Type: Motor Circuit Interrupter
• Poles: 3
• Amperage Rating: 3 Amps
• Voltage Rating: 600 VAC
• Frame Type: E6-A ETI
• Instantaneous Trip Settings:
  • H = 35A
  • 4 = 30A
  • 3 = 23A
  • 2 = 17A
  • L = 10A
• Terminals: Includes line-side and load-side terminals
• Approximate Shipping Height: 6.35 in
• Approximate Shipping Weight: 3.0 lbs

Material Compliance and Certifications

• Industry Standards: Circuit breakers and motor circuit interrupters of this type are manufactured to meet the applicable UL and industry electrical safety standards that were in place at the time of production for molded case motor protection devices.
• Electrical-Grade Materials: Components are constructed from electrical-grade materials designed for safe operation within rated voltage and current limits when installed according to manufacturer guidelines and applicable electrical codes.

Where It Works Best

• The E63A003 motor circuit interrupter is well-suited for maintaining or servicing equipment that relies on the E6-A ETI frame platform. Typical applications include:
• Industrial motor control panels
• Motor control centers (MCCs)
• Manufacturing and processing equipment
• Pump and compressor control systems
• Electrical distribution panels supporting motor loads
