E3015 - 15A Circuit Breaker

E3015 - 15A Circuit Breaker

When you're dealing with a three-phase electrical system, the replacement breaker has to match the original setup closely—otherwise the panel just won’t behave the way it should. The E3015 15 Amp 3-Pole Circuit Breaker is built for exactly that kind of situation. It’s a Type E thermal-magnetic breaker designed for systems that require a 15 Amp rating, 3-pole configuration, and 240VAC service, commonly found in legacy industrial and commercial electrical distribution equipment.

The E3015 is rated for a 10kA interrupting capacity at 240VAC, making it suitable for a range of general-purpose applications within its listed electrical limits. It also includes a non-interchangeable trip unit, which helps maintain the original factory configuration of the equipment it is installed in. With a 40°C temperature rating and included load terminals, it fits cleanly into compatible panels without requiring modifications to the existing layout.

In real-world use, this breaker is typically selected during maintenance or replacement work where the goal is simple—keep the system running as it was originally designed. Matching the correct amperage, pole count, and voltage rating helps avoid unnecessary changes to the panel and keeps downtime to a minimum.

Key Features and Benefits

• 15 Amp rating for three-phase circuit protection
• 3-pole configuration for 240VAC systems
• Type E thermal-magnetic breaker design
• Thermal and magnetic trip response for overloads and short circuits
• Non-interchangeable trip unit maintains original configuration
• 10kA interrupting capacity at 240VAC
• Rated for operation up to 40°C (104°F)
• Includes load terminals for compatible installations
• Compact footprint for use in existing electrical systems
• Built to last for ongoing maintenance and replacement applications
• Suitable for form, fit, and functional replacement work


Technical Specifications

• Part Number: E3015

• Type: E

• Product Type: Thermal-Magnetic Circuit Breaker

• Amperage Rating: 15 Amps

• Poles: 3

• Voltage Rating: 240 VAC

• Interrupting Capacity: 10kA @ 240VAC

• Trip Unit: Non-Interchangeable

• Temperature Rating: 40°C (104°F)

• Included Terminals: Load Terminals

• Dimensions:
  • Width: 4.13 in
  • Height: 6.00 in
  • Depth: 3.31 in
  • Dimensions: 4.13"W x 6.00"H x 3.31"D
• Approximate Shipping Weight: 4.50 lbs


Material Compliance and Certifications

The E3015 should be installed and maintained by qualified electrical personnel in accordance with applicable electrical codes and manufacturer instructions. Before installation, confirm compatibility with the existing system, including voltage rating, amperage rating, interrupting capacity, pole configuration, and physical fit. No additional compliance or certification information was provided in the available specifications.

Where It Works Best

• The E3015 is commonly used in:
• Commercial electrical distribution systems
• Industrial facilities and manufacturing environments
• Institutional buildings such as schools and healthcare facilities
• Maintenance and repair work on existing equipment
• Three-phase systems requiring a Type E circuit breaker replacement
• 240VAC electrical distribution systems
• Legacy installations where matching original breaker specifications is required
• Equipment requiring a 15 Amp 3-pole breaker configuration
