When keeping existing industrial equipment running, finding the right replacement relay matters. The D23MR60A Type M Relay from Cutler Hammer is a 6-pole, 10-amp control relay designed for applications that require a 120 VAC coil and dependable switching of control circuits. Featuring reversible contacts and an open-style design, this relay is commonly used in motor control systems, industrial machinery, control panels, and other electrical equipment where maintaining original specifications is important.

Whether you're replacing a worn component during scheduled maintenance or troubleshooting a control system issue, the D23MR60A helps restore functionality while preserving the original design of compatible equipment. Its six-pole configuration provides multiple switching points for complex control schemes, making it a practical choice for machinery that relies on coordinated control functions and auxiliary circuits.

This relay was built for industrial environments where equipment is expected to remain in service for years. The combination of a 120 VAC, 60 Hz coil, 10-amp contact rating, and 300V AC maximum operating voltage makes it suitable for a wide range of control applications found in manufacturing facilities, processing plants, material handling systems, and machine tool installations.

Key Features and Benefits

• Type M industrial control relay
• Six-pole configuration for multiple control functions
• Rated 10 amperes, up to 300V AC maximum
• 120 VAC, 60 Hz control coil
• Reversible contact design for compatibility with existing control circuits
• Open-style enclosure configuration
• Suitable for industrial machinery and control panel applications
• Helps maintain original equipment specifications during replacement projects
• Compact dimensions for installation in existing panel layouts
• Built to last in properly maintained electrical systems
• Associated with catalog numbers D23MB, D26MPR, D26MPL, and D26MPS


Technical Specifications

• Part Number: D23MR60A

• Manufacturer: Cutler Hammer

• Type: M Relay

• Sub-Category: Relay

• Poles: 6

• Amperes: 10A

• Maximum Voltage Rating: 300V AC

• Coil Voltage: 120 VAC

• Frequency: 60 Hz

• Contact Style: Reversible Contacts

• Enclosure Type: Open

• Dimensions:
  • Height: 2.38 in.
  • Width: 3.50 in.
  • Depth: 3.68 in.

Material Compliance and Certifications

The D23MR60A should be installed and serviced by qualified personnel in accordance with applicable electrical codes, manufacturer requirements, and facility maintenance procedures. Before installation, users should verify compatibility with their specific application, including coil voltage, contact arrangement, current rating, and overall control circuit requirements. Any compliance, certification, or equipment-specific approval requirements should be confirmed based on the system in which the relay is being used.

Where It Works Best

The D23MR60A Type M Relay is commonly used in:

• Industrial control panels
• Motor control systems
• Manufacturing equipment
• Material handling machinery
• Process control systems
• Machine tool controls
• Auxiliary control circuits
• Equipment sequencing applications
• Legacy electrical systems requiring a compatible Type M relay replacement
• Facilities maintaining existing automation and control assemblies

Its combination of a 6-pole design, 120 VAC coil, reversible contacts, and compact dimensions makes the D23MR60A well suited for maintaining compatible industrial control equipment while preserving the original operating characteristics of the application.
