CSR2225N - 225Amp Circuit Breaker

CSR2225N - 225Amp Circuit Breaker

When reliable service entrance protection matters, the Eaton CSR2225N Main Circuit Breaker is built to handle the job. Rated at 225 amps and designed as a two-pole main breaker, this unit serves as the primary disconnect for compatible electrical systems while helping protect wiring and connected equipment from overloads and short-circuit conditions. Whether you're replacing an existing breaker, upgrading service equipment, or completing a new installation, the CSR2225N provides the ampacity and protection required for demanding residential and light commercial applications.

Designed for use in Type ECC Unit Enclosures, the Eaton CSR2225N combines a compact footprint with a 25 kAIC interrupting rating, helping provide protection during high fault-current events. The breaker accepts conductor sizes ranging from #2 AWG to 300 kcmil, making it easier to match existing wiring configurations during service upgrades and replacement projects. As part of Eaton's CH-family electrical equipment, it is intended for applications where maintaining proper equipment compatibility is an important part of the installation.

For electricians, contractors, and maintenance professionals, selecting the correct main breaker is about more than just amperage. The CSR2225N provides the combination of enclosure compatibility, fault-current protection, and conductor flexibility needed for a straightforward installation. Its UL 489 listing and Eaton-backed quality make it a practical choice for projects requiring a 225A main circuit breaker in a 120/240V electrical system.

Key Features and Benefits

• 225-amp main circuit breaker for service entrance and distribution applications
• Two-pole design for 120/240V AC electrical systems
• Functions as the primary disconnect and overcurrent protection device
• Compatible with Eaton Type ECC Unit Enclosures
• High 25 kAIC interrupting rating for fault-current protection
• Accepts conductor sizes from #2 AWG to 300 kcmil
• CH-series main breaker configuration
• Designed for residential and light commercial electrical installations
• Helps protect wiring and connected equipment from overloads and short circuits
• Backed by Eaton’s limited lifetime warranty


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: CSR2225N

• UPC: 782114106242

• Product Type: Main Breaker

• Type: Standard Circuit Breaker

• Frame Type: CSR

• Main Circuit Breaker Series: CH

• Amperage Rating: 225A

• Voltage Rating: 120/240V AC

• Number of Poles: 2

• Interrupt Rating: 25 kAIC

• Wire Size Range: #2 AWG – 300 kcmil

• Enclosure Compatibility: Type ECC Unit Enclosures

• Dimensions:
  • Length: 3.1 in.
  • Width: 2 in.
  • Height: 3.1 in.
• Weight: 3 lb

• Warranty: Limited Lifetime


Material Compliance and Certifications

The Eaton CSR2225N is UL 489 Listed, demonstrating compliance with recognized industry safety and performance standards for molded-case circuit breakers. This certification confirms the breaker has been evaluated for use in electrical distribution systems and is designed to provide dependable protection when installed in accordance with applicable electrical codes and manufacturer guidelines.

Where It Works Best

• Residential service entrance equipment
• Single-family home electrical services
• Large residential service upgrades
• Multi-family housing and apartment electrical systems
• Light commercial buildings
• Main breaker replacement projects
• Electrical panel modernization applications
• New construction electrical installations
• Eaton CH-based systems utilizing compatible Type ECC Unit Enclosures
